SEER Light/SEER Light Extend Controller: Component Names and Locations
C data transfer cable Used to transfer data from the SEER Light recorder. When not in use, store the cable in
the guide on the backside panel.
D
power button
Used to turn the power on and off.
E Holter card slot Used to insert a Holter card.
F LCD (liquid crystal display) Displays operating conditions.
G F1 button Used to enter the preview mode (wired or wireless) to confirm the quality of ECG
recording.
H F2 button Used to enter the data transfer mode to transmit data to a Holter card.
I F3 button Used to start recording of the SEER Light recorder and to start transferring data to a
Holter card.
J
set-up button (
)
Used to select settings.
K patient information entry
buttons
Enter the patient’s alphanumeric information.
L battery cover In direction indicated, slide the cover open and place four new alkaline AAA type batteries
in the battery box.
Table 4. Controller Parts List (Continued)
Item Name Description
