3.3 Timers
The V7768/V7769 provide four user-programmable timers (two 16-bit and two
32-bit) which are completely dedicated to user applications and are not required
for any standard system function. Each timer is clocked by independent
generators with selectable rates of 2 MHz, 1 MHz, 500 kHz and 250 kHz. Each
timer may be independently enabled and each is capable of generating a system
interrupt on timeout.
Events can be timed by either polling the timers or enabling the interrupt
capability of the timer. A status register allows for application software to
determine which timer is the cause of any interrupt.
3.3.1 Timer Control Status Register 1 (TCSR1)
The timers are controlled and monitored via the Timer Control Status Register 1
(TCSR1) located at offset 0x00 from the address in BAR2. The mapping of the bits
in this register are shown in Table 3-2.
Each timer has an independently selectable clock source which is selected by the
bit pattern in the “Timer x Clock Select” field as shown in Table 3-3.
Table 3-2 TCSR1 Bit Mapping
Field Bits Read or Write
Timer 1 Caused IRQ TCSR1[0] R/W
Timer 1 Enable TCSR1[1] R/W
Timer 1 IRQ Enable TCSR1[2] R/W
Timer 1 Clock Select TCSR1[4..3] R/W
Timer 2 Caused IRQ TCSR1[8] R/W
Timer 2 Enable TCSR1[9] R/W
Timer 2 IRQ Enable TCSR1[10] R/W
Timer 2 Clock Select TCSR1[12..11] R/W
Timer 3 Caused IRQ TCSR1[16] R/W
Timer 3 Enable TCSR1[17] R/W
Timer 3 IRQ Enable TCSR1[18] R/W
Timer 3 Clock Select TCSR1[20..19] R/W
Timer 4 Caused IRQ TCSR1[24] R/W
Timer 4 Enable TCSR1[25] R/W
Timer 4 IRQ Enable TCSR1[26] R/W
Timer 4 Clock Select TCSR1[28..27] R/W
Reserved All Other Bits R/W
All of these bits default to “0” after system reset.
Table 3-3 Selectable Clock Source for Timers
Clock Ratio MSb LSb
2 MHz 0 0
1 MHz 0 1
500 kHz 1 0
250 kHz 1 1
