Appendix B: AMI BIOS Setup Utility 87
B.7 Chipset Setup Menu
Select the various options for chipsets located in the system (for example, the CPU
configuration and configurations for the North and South Bridge). The settings
for the chipsets are processor dependent and care must be used when changing
settings from the defaults set at the factory. Below is a sample of the Chipset Setup
screen; the actual options on your system may vary.
NOTE
Changes in this screen can cause the system to malfunction. If
problems are noted after changes have been made, reboot the
system and access the BIOS. From the Exit menu select ‘
Load
Failsafe Defaults
’ and reboot the system. If the system failure
prevents access to the BIOS screens, refer to Chapter 1 “Installation
and Setup” for instructions on clearing the CMOS.
Table B-7 AMI BIOS Chipset Menu
002.53 (C) Copyright 1985-2002, American Megatrends, Inc.
BIOS SETUP UTILITY
Main Advanced PCIPnP Boot Security Chipset Exit
Advanced Chipset Settings Intel Montara GML
NorthBridge chipset
Configuration options.
←→ Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
WARNING: Setting wrong values in below section
may cause system to malfunction.
Intel Montara NorthBridge Configuration
Hance Rapids SouthBridge Configuration
CPCI (HINT HB6) Bridge Configuration
Lan (8254EB) Port Routing Options
To Next Page
