GE V7768 - Table A-2 V7768 VME Connector Pinout (P2)

Appendix A: Connector Pinouts 61
Table A-2 V7768 VME Connector Pinout (P2)
Pin No. Row A Row B Row C Row D Row Z
1 GND +5V SP1_TX CONN[1] CONN[2]
2 USB_P5N GND SP1_RTS# CONN[3] GND
3 USB_P5P N/C SP1_DTR# CONN[4] CONN[5]
4 USB_OC5# A24 SP1_RX CONN[6] GND
5GND A25 SP1_DCD# CONN[7] CONN[8]
6 USB_P4N A26 SP1_CTS# CONN[9] GND
7 USB_P4P A27 SP1_DSR# CONN[10] CONN[11]
8 USB_OC4# A28 SP1_RI# CONN[12] GND
9 GND A29 RTM_SCONF_GP CONN[13] CONN[14]
10 USB_P3P A30 VCC_5.0 CONN[15] GND
11 USB_P3N A31 -12 V CONN[16] CONN[17]
12 USB_OC3# GND GND CONN[18] GND
13 GND +5 V SATA1_RXN CONN[19] CONN[20]
14 USB_P2N D16 SATA1_RXP CONN[21] GND
15 USB_P2P D17 GND CONN[22] CONN[23]
16 USB_OC2# D18 SATA1_TXN CONN[24] GND
17 GND D19 SATA1_TXP CONN[25] CONN[26]
18 +5 V D20 GND CONN[27] GND
19 +12 V D21 GND CONN[28] CONN[29]
20 GND D22 SATA2_RXN CONN[30] GND
21 N/C D23 SATA2_RXP CONN[31] CONN[32]
22 N/C GND GND CONN[33] GND
23 GND D24 SATA2_TXN CONN[34] CONN[35]
24 N/C D25 SATA2_TXP CONN[36] GND
25 N/C D26 GND CONN[37] CONN[38]
26 GND D27 GND CONN[39] GND
27 N/C D28 GND CONN[40] CONN[41]
28 N/C D29 GND CONN[42] GND
29 GND D30 N/C CONN[43] CONN[44]
30 N/C D31 N/C CONN[45] GND
31 N/C GND N/C GND CONN[46]
32 GND +5 V N/C +5 V GND
N/C indicates No Connection
