10.1.3 Bit Operation Functions Exclusive OR
The Exclusive OR function compares each bit in bit string I1 with the corresponding bit
in string I2. If the bits are different, a 1 is placed in the corresponding position in the
output bit string.
Input 1
Input 2
Output
OK Enable
XOR_
WORD
I1 Q
I2
I1 and the corresponding bit in string I2, beginning at the least significant bit in each. For
each two bits examined, if only one is 1, then a 1 is placed in the corresponding location
in bit string Q. The Exclusive OR function passes power flow to the right whenever
power is received.
If string I2 and output string Q begin at the same reference, a 1 placed in string I1 will
cause the corresponding bit in string I2 to alternate between 0 and 1, changing state with
each scan as long as power is received. Longer cycles can be programmed by pulsing the
power flow to the function at twice the desired rate of flashing; the power flow pulse
should be one scan long (one-shot type coil or self-resetting timer).
The Exclusive OR function is useful for quickly comparing two bit strings, or to blink a
group of bits at the rate of one ON state per two scans.
10.1.3.1 Parameters of the Exclusive OR Function
Input/ Output
Choices
Description
enable flow
When the function is enabled, the operation is
performed.
I1
I, Q, M, T, S, G, R, AI,
AQ, constant
Constant or reference for the first word to be
XORed.
I2
I, Q, M, T, S, G, R, AI,
AQ, constant
Constant or reference for the second word to be
XORed.
ok
flow, none
The OK output is energized whenever enable is
energized.
Q
I, Q, M, T, SA, SB, SC
(not S), G, R, AI, AQ
Output Q contains the result of the operation.
126 GFK-1503E VersaMax PLC User Manual
