3.10 Configurable Memory
CPUE05 provides a total of 128K bytes of configurable user memory. This 64K of
memory is use for the application program, hardware configuration, registers (%R),
analog inputs (%AI), and analog outputs (%AQ). The amount of memory allocated to the
application program and hardware configuration are automatically determined by the
actual program and configuration entered from the programmer. The rest of the 64K bytes
can be easily configured to suit the application.
Configurable memory 128K bytes maximum
Application program size (not configurable) 128 bytes minimum
Hardware configuration size (not
configurable)
528 bytes minimum
Registers (%R) 256 bytes minimum
Analog Inputs (%AI) 256 bytes minimum
Analog Outputs (%AQ) 256 bytes minimum
48 GFK-1503E VersaMax PLC User Manual
