GE VersaMax PLC

Sizes of Exponential Functions, Radian Conversion,
Relational Functions
The size of a function is the number of bytes consumed in user logic space for each
instance of the function in a ladder diagram application program.
Group
Function
CPU001/002 CPU005/E05
Incre-
ment
Size
Enabled Disabled Enabled Disabled
Exponential
Power of e 592 12 393 10
–
11
Power of X 365 12 249 10
–
17
Radian Convert RAD to DEG 328 12 214 10
–
11
Conversion Convert DEG to RAD 106 12 70 10
–
11
Relational
Equal (INT)
43 12 30 10
–
10
Equal (DINT)
50 12 37 10
–
16
Equal (REAL)
60 12 41 10
–
14
Not Equal (INT)
40 12 30 10
–
10
Not Equal (DINT)
45 12 30 10
–
16
Not Equal (REAL)
60 12 40 10
–
14
Greater Than (INT)
40 12 30 10
–
10
Greater Than (DINT)
45 12 30 10
–
16
Greater Than (REAL)
60 12 40 10
–
14
Greater Than/Equal (INT)
40 12 30 10
–
10
Greater Than/Equal
(DINT)
46 12 30 10
–
10
Greater Than/Equal
(REAL)
60 12 40 10
–
14
Less Than (INT)
40 12 30 10
–
10
Less Than (DINT)
46 12 30 10
–
16
Less Than (REAL)
60 12 40 10
–
14
Less Than/Equal (INT)
40 12 30 10
–
10
Less Than/Equal (DINT)
46 12 30 10
–
16
Less Than/Equal (REAL)
60 12 40 10
–
14
Range (INT)
50 12 33 10
–
13
Range (DINT)
55 12 40 10
–
22
Range (WORD)
50 12 33 10
–
13
304 GFK-1503E VersaMax PLC User Manual
