10.3.5.1 Parameters of the COMMREQ Function
Input/
Output
Choices
Description
enable flow
When the function is energized, the
communications request is performed.
IN
R, AI, AQ
IN contains the first word of the command block.
SYSID
I, Q, M, T, G, R, AI, AQ,
constant
SYSID contains the rack number (most
significant byte) and slot number (least
significant byte) of the target device.
TASK
R AI, AQ, constant
TASK contains the task ID of the process on the
target device.
FT
flow, none
FT is energized if an error is detected processing
the COMM REQ:
1. The specified target address is not present
(SYSID).
2. The specified task is not valid for the device
(TASK).
3. The data length is 0.
4. The device’s status pointer address (in the
command block) does not exist.
10.3.5.2 Command Block for the COMMREQ Function
The Command Block starts at the reference specified in COMMREQ parameter IN. The
length of the Command Block depends on the amount of data sent to the device.
The Command Block contains the data to be communicated to the other device, plus
information related to the execution of the COMM REQ. The Command Block has the
following structure:
address Length (in words)
address + 1 Wait/No Wait Flag
address + 2 Status Pointer Memory
address + 3 Status Pointer Offset
address + 4 Idle Timeout Value
address + 5 Maximum Communication Time
address + 6 to
address + 133
Data Block
154 GFK-1503E VersaMax PLC User Manual
