The LED on the EZ Program Store device turns amber and the Port 2 LED on the PLC
blinks.
4. Wait for the update to complete. Reading and writing large programs, hardware
configurations, and reference tables to or from the EZ Program Store device may take
30 seconds or more to complete.
When the device’s LED turns solid green and the CPU’s Run LED starts blinking, the
update has completed successfully.
EZ Program
Store Device
LED
When the PLC is placed into Run mode (by moving the Run/Stop switch from Stop/Off to
Run/On position) it uses the new data immediately.
The EZ Program Store Device GFK-1503E User Manual 299
