4.7.3.3 Connector and Cable Specifications for Port 1
Vendor Part numbers below are provided for reference only. Any part that meets the same
specification can be used.
Cable:
Computer cable, overall braid over foil shield
Belden 9610
5 conductor
†
30 Volt / 80°C (176°F)
24 AWG tinned copper, 7x32 stranding
9 Pin Male
Connector:
Type:
Vendor:
Plug:
Pin:
Crimp
ITT/Cannon DEA9PK87F0 030-2487-017
AMP 205204-1 66506-9
Solder
ITT/Cannon ZDE9P
–
AMP 747904-2
–
Connector
Shell:
Kit
††
– ITT Cannon DE121073-54 [9-pin size backshell kit]:
Metal-Plated Plastic (Plastic with Nickel over Copper)
†
Cable Grounding Clamp (included)
40° cable exit design to maintain low-profile installation
Plus – ITT Cannon 250-8501-010 [Extended Jackscrew]:
Threaded with #4-40 for secure attachment to CPU001 port
†
Order Qty 2 for each cable shell ordered
†
Critical Information – any other part selected should meet or exceed this requirement.
Installation GFK-1503E User Manual 63
