Parameter Description
Default Choices
Scan Parameters
Sweep Mode Normal: sweep runs until it is complete. Normal Normal, Constant Sweep
Constant: sweep runs for time specified in
Sweep Tmr.
Sweep Times
(mSecs)
If Constant Sweep mode was selected, a
Constant Sweep Time (in milliseconds) can be
specified.
100mS 5–200mS
Settings Parameters
I/O Scan-Stop Determines whether I/O is to be scanned while
the PLC is in STOP mode.
No Yes, No
Powerup Mode Selects powerup mode. Last Last, Stop, Run
Logic/Configura-
tion From
Source of program and configuration when the
PLC is powered up.
RAM RAM, Flash
Registers Selects source of register data when PLC is
powered up.
RAM RAM, Flash
Passwords Determines whether the password feature is
enabled or disabled. (If passwords are disabled,
the only way to enable them is to clear the PLC
memory.)
Enabled Enabled, Disabled
Checksum
Words per
Sweep
The number words in the application program to
be checksummed each sweep
8 8 to 32
Default Modem
Turnaround
Time
Modem turnaround time (10ms/unit) This is the
time required for the modem to start data
transmission after receiving the transmit request.
0mS 0–255mS
Default Idle
Time
Time (in seconds) the CPU waits to receive the
next message from the programming device
before it assumes that the programming device
has failed and proceeds to its base state.
Communication with the programmer is
terminated and will have to be reestablished.
10 1–60
SFC Timer
Faults
Enables or disables viewing of SFC Timer faults. Disabled Enabled/Disabled
SNP ID None Editable
Switch Run/Stop Determines whether the switch will control
Run/Stop mode operation
Enabled Enabled, Disabled
Switch Memory
Protect
Determines whether the switch will control RAM
memory protection.
Disabled Enabled, Disabled
Diagnostics Unless your application requires unusually fast
power up, leave this setting ENABLED. The
DISABLED setting causes the PLC to power up
without running diagnostics.
Enabled Enabled, Disabled
Configuration GFK-1503E User Manual 73
