September 2007
7-8 Advanced Programming
SYSTEM MODE Option
(cont.)
The next prompt is used to choose between the two available analog
output ranges and resolutions. All units are shipped from the factory
with a range of 0.00-100.00% with a resolution of 0.01%, but a range
of 0.000-10.000% with a resolution of 0.001% is available for special
applications.
If you pressed
[Y] above, programming of this submenu is complete.
Proceed to the final prompt on this page. Otherwise, continue with the
next prompt.
IMPORTANT: Always consult the factory before choosing the
special range/resolution setting.
The following prompt, which appears only if [Y] was pressed above,
is used to specify an offset for a zero-suppressed range.
You may now do one of the following:
• Press [N] as many times as necessary to select another Calibrate
System menu option. Then, press
[Y] and proceed to the appropriate
section of this chapter for instructions.
• Press [N] repeatedly until you reach the Done? option of the
Calibrate System menu, then press
[Y] to return to the top level of
the Advanced Menu.
Calibration Range:
Press [Y] or [Enter] to accept this
range, or press
[N] is you wish to
use the alternate range.
0.00% - 100.00%?
Calibration Range:
Press [Y] or [Enter] to accept this
range, or press
[N] is you wish to
use the default range.
0.000% - 10.000%?
Enter low %O2 value:
To accept the current value, press
[Y] or [Enter]. To change the
current value, use the numeric
keys to enter a new value and
press
[Y] or [Enter] twice.
%O2 [x.x]
CALIBRATE SYSTEM
You have now completed the
programming of this submenu.
System Mode?
