5-10 Basic Programming
SET LOW INPUT VALUE
Option
The Set Low Input Value option lets you specify the %O
2
value in the
gas that corresponds to a 4.00 mA current at the analog output.
Note: This option appears if DriftCal is ON or OFF and if a one- or
two-gas calibration has been selected.
To use the Set Low Input Value option, proceed as follows:
1. Press
[N] until the following prompt appears:
2. At the above screen, do one of the following:
• Press [Y] or [ENTER] to accept the current low input value (0.00
in the above example). Then, go to Step 4.
• Use the numeric keys to enter a new low input value (5.00 in
the example that follows). Then, go to Step 3.
3. If you entered a new low input value:
4. Complete the procedure as follows:
You may now do one of the following:
• Press [N] as many times as necessary to select another Basic Menu
option. Then, press
[Y] and proceed to the appropriate section for
instructions.
• Press [N] repeatedly until the Resume? option appears. Then, press
[Y] to return to Operate Mode.
BASIC MENU
Press [Y] or [ENTER] to set the
low (4 mA) input value.
Set Low Input Value?
mA Output 4 mA Value
Go to Step 2.
%O2 [0.00]:
mA Output 4 mA Value
Press [Y] or [ENTER] to accept
the new low (4 mA) input value.
%O2 [0.00]:5.00
BASIC MENU
The Low Input Value has been
set.
Set Low Input Value?
To Next Page
