PRESSURE CURVE Option
(cont.)
If you selected Numeric Entry as the Calibrate Mode:
At the mmHg mV prompt, enter the listed pressure signal mV value
corresponding to the mmHg value entered at the previous prompt.
Obtain this data from your Calibration Sheet (see page 8-6 for a
sample calibration sheet).
The mmHg and mmHg mV prompts repeat until the total number of
data points specified at the # Points prompt have been entered. This
completes the programming of the Pressure Curve option, and the
XMO2 returns to the Calibrate System menu.
If you selected Introduce Gases as the Calibrate Mode:
At the mmHg prompt, enter the pressure that you intend to use.
The XMO2 displays working... as it records the calibration data, and
then repeats the mmHg and Introduce xxx.x mmHg prompts for the
number of points specified at the # Points prompt. This completes the
programming of the Pressure Curve option, and the XMO2 returns to
the Calibrate System? menu.
Enter Pressure Curve
To accept the current value, press
[Y] or [Enter]. To change the
current value, use the numeric
keys to enter a new value and
press
[Y] or [Enter] twice.
mmHg mV [-xxx.x]:
Enter Pressure Curve
To accept the current value, press
[Y] or [Enter]. To change the
current value, use the numeric
keys to enter a new value and
press
[Y] or [Enter] twice.
mmHg [xxx.x]:
Introduce xxx.x mmHg
Apply the specified pressure,
then press
[Y] or [Enter].
Press [YES] when ready.
Press [YES] when settled.
The mV value corresponding to
the above mmHg value is shown.
When the displayed value
stabilizes, press
[Y] or [Enter].
-xxx.x mmHg mV
