General Programming 6-17

September 2007

PRESSURE GRID Option

(cont.)

If you selected Introduce Gases and [Y]:

If you selected Introduce Gases at the Calibrate Mode prompt and

[Y]

at the Enter Point? prompt, you may begin calibrating the XMO2 at

the current %O2 and pressure values by introducing a gas with the

appropriate oxygen concentration and pressure.

The XMO2 displays working... as it records the calibration data, and

then returns you to the Enter Point? prompt on page 6-15.

If you selected Introduce Gases and [N]:

If you selected Introduce Gases at the Calibrate Mode prompt and

[N]

at the Enter Point? prompt, the Interpolate Point? prompt is used to

have the XMO2 perform a linear interpolation to determine the

corresponding mV value for the current %O2 and pressure values.

Note: The XMO2 linear interpolation capability is useful when you

do not have a calibration gas with the required oxygen

concentration and pressure for a given point.

The XMO2 displays working... as it records the calibration data, and

then returns you to the Enter Point? prompt on page 6-15.

Introduce x.xx %O2 @xxx.x mmHg

Initiate the calibration gas flow,

then press

[Y] or [Enter].

Press [YES] when ready.

Press [YES] when settled.

When the displayed mV and

pressure values stabilize, press

[Y] or [Enter].

-xxx.x O2 mV xxx.x mmHg

x.xx %O2, xxx.x mmHg

Press [Y] or [Enter] to begin the

interpolation, or press

[N] to

return to the Enter Point?

prompt.

Interpolate Point?
