GEA VARIVENT X R Series User Manual

3.1.4 Protective devices
No safety devices are attached to this valve.
3.2
Technical data
3.2.1 Type plate
The type plate clearly identies the valve.
The type plate provides the following key data:
Key data of the valve
Characteristics Values
Type X_R
Serial Serial number
Material 1.4404(AISI316L) / EPDM
Control air pressure bar/psi 6 (87)
Product pressure bar/psi 5 (72.5)
3.2.2 Technical data
Refer to the following tables for the key technical data of the valve:
Technical data: Valve
Designation Description
Size DN 25 to DN 100
1" to 4" OD
Material of product contact parts Stainless steel 1.4404
Fitting position Any position, if valve and pipe system can drain
properly
28 / 104 - 3.2 Technical data
0000000881 - 001 - EN-GB
