9.6.4 Placing the valve insert in the housing
1. Place the valve insert into the hous-
ing.
®
! The bearing disk (4) and the seal
disk (3) may not hit the rod of the
valve disk when the valve insert is t-
ted.
3
4
Þ
The valve insert is placed into the housing.
9.6.5 Mounting the control top
ATTENTION
The switch bar is sensitive and must be protected from impact stress.
Damage to switch bar.
●
Protect the switch bar against impact stress.
9.6 Installing the valve - 69 / 104
