Spring-to-open valve (NO) with control top T.VIS
INFO Removal step: remove the clamp connection between the housing and lan-
tern
Prerequisites
●
No solenoid valve must be actuated electrically or manually.
●
The pneumatic and electrical connections on the plant side can remain on the
control top.
Tools
●
Philips screwdriver
●
Slotted screwdriver
●
Jaw wrench a/f 10
●
Jaw wrench a/f 13
1. Depressurize actuator, 0 bar.
2. Remove the clamp connection (43)
between the housing and the lantern.
Þ
The clamp connection between the housing and the lantern has been r
emoved.
9.5 Removing the valve - 55 / 104
