4. CONFIGURATION
4.16.10. MSG.OU - Selecting the output message
Acronym Scrolling message Submenu Attributes
MSG.OU NUMBER OF SCROLLING MESSAGE AT OUTPUT ACT OUTPU R W
The parameter shows and sets the number of the message assigned to activation of the output, i.e., the scrolling messa-
ge shown on the display.
For more information on scrolling messages, see paragraph “3.1.2.2. Scrolling messages” on page 34.
If the parameter is set to “0” no message will be displayed when the output is activated.
The same message number can be assigned to different outputs.
Unit of measurement: Message number
Options: 0...25
4.16.11. CY.TIM - Cycle time of output
Acronym Scrolling message Submenu Attributes
CY.TIM CYCLE TIME OUTPU R W
The parameter shows and sets the slicing period of the output.
The parameter appears if the parameter F.ou.x = HEAT o F.ou.x = COOL.
The slicing period is the cycle time, i.e., the sum of ON time and OFF time proportional to the value of Heat or Cool
power.
Example
If Heat power is 25% and the 25% the cycle time is 10.0 seconds, the output is active for 2.5 seconds and inacti-
ve for 7.5 seconds.
Burst Firing (BF) mode has a variable cycle time, optimized to transfer power as quickly as possible. The minimum inter-
val for ON or OFF equals the electrical cycle (20 ms at 50 Hz).
The ON and OFF times are multiples of the minimum time.
Example
If Heat power is 25% and the line frequency is 50 Hz, the cycle time is 80 ms. The output is active for 20 ms and
inactive for 60 ms (= 3 × 20 ms, equal to the remaining 75% of the cycle time).
Unit of measurement: Seconds
Options: 0.0...20.0 for digital and Triac outputs. There is Burst Firing (BF) with 0.0.
1...200 for relay output
