4. CONFIGURATION
4.12.5. THR.PE - Percentage of HB current compared to calibration
Acronym Scrolling message Submenu Attributes
THR.PE PERCENTAGE HB ALARM SP IN HB CALIB AL.HB R W
The parameter shows and sets the current draw value for the Heater Break alarm.
This value is expressed as a percentage of the current draw value set during calibration.
For more information on this calibration, see paragraph LOW.ON.
See also paragraph “4.25. Submenu US.CAL – User calibrations” on page 131.
Unit of measurement: %
Options: 0.0...100.0 (default value = 80.0)
4.12.6. OUT - Control output associated with HB alarm
Acronym Scrolling message Submenu Attributes
OUT CONTROL OUTPUT HB AL AL.HB R W
The parameter shows and sets the number of the control output associated with the alarm.
This is the output whose ON/OFF state is checked, as indicated in the description of the LOW.ON, HIG.ON and HI.OFF
parameters.
Unit of measurement: Number
Options: 1...4
4.12.7. LoAd - Selecting type of connected load
Acronym Scrolling message Submenu Attributes
LoAd TYPE OF LOAD CONFIGURATION AL.HB R W
The parameter shows and sets the type of load connected to the control output.
For more information on load type, see paragraph “5.6.2. HB Alarm” on page 143.
Unit of measurement: -
Options: MONO = Monophase power supply, with current transformer CT1 only (if current transformer CT2
is present it is ignored)
STAR = 3-phase star power supply without neutre, with CT1 and CT2
DELTA = 3-phase delta power supply with CT1 and CT2
4.12.8. MSG.HB - Message associated with tripping of HB alarm
Acronym Scrolling message Submenu Attributes
MSG.HB SCROLLING MESSAGE AT HB ACT AL.HB R W
The parameter shows and sets the number of the message associated with tripping of the HB alarm, i.e., the scrolling
message shown on the display.
For more information on scrolling messages, see paragraph “3.1.2.2. Scrolling messages” on page 34.
If the parameter is set to “0” no message will be displayed when the alarm trips.
The same message number can be assigned to different alarms.
Unit of measurement: Message number
Options: 0...25
