4. CONFIGURATION
4.15.1. I.DIG.N - Selecting the digital input
Acronym Scrolling message Submenu Attributes
I.DIG.N DIGITAL INPUT NUMBER I.DIGT R W
The parameter shows and sets the identifying number of the digital input to be configured.
Unit of measurement: Number
Options: 1...2 for model 650 with 2 digital inputs option
1...3 for model 650 with 3 digital inputs option
1...5 for models 1250 and 1350 with 5 digital inputs option
4.15.2. S.in.x - Defining the input state
Acronym Scrolling message Submenu Attributes
S.in.x DIGITAL INPUT STATUS I.DIGT R W
The parameter shows and sets the state of the input with identifying number “x”.
The direct digital input is active when there is current in the digital input or the contact is closed.
The inverse digital input is active when there is no current in the digital input or the contact is open.
Digital inputs can be forced so that they are always on or off.
Unit of measurement: -
Options: DIREC = Direct digital input
INVRS = Inverse digital input
OFF = Digital input forced off
ON = Digital input forced on
4.15.3. F.in.x - Selecting the assigned function
Acronym Scrolling message Submenu Attributes
F.in.x DIGITAL INPUT FUNCTION I.DIGT R W
The parameter shows and sets the function assigned to the digital input with identifying number “x”.
Unit of measurement: -
Options: NONE = No assigned function
AU-MA = Automatic-Manual control
LO-RE = Local-Remote setpoint mode
HOLD = Hold value of main input
AL.ACK = Reset alarm latches
S.TUNE = Activate Self-Tuning
A.TUNE = Activate Auto-Tuning
ON-OF = Software ON-OFF
FKEY = Block F key
WRI.EN = Enable writing of configuration parameters
if the Multiset function is enabled:
SEL.L = Select setpoint SETP1...SETP2 or SETP1...SETP4 low bit
SEL.H =
Select set point SETP1...SETP4 high bit Model “Programmer enabled
SEL.L and SEL.H” have the meaning of selection Nr. program
if the Timer function is enabled:
T.STST = START/STOP timer
T.RST = RESET timer
if the Programmer function is enabled:
P.STST = START/STOP programmer base times
P.STRT = START programmer base times
P.STOP = STOP programmer base times
P.RST = RESET programmer base times
P.SKP = SKIP to end of program (end cycle)
ST.SKP = SKIP to end of step
ST.ENB
= STEP ENABLE: input with consent function at start of step
if the Logic Options function is enabled:
FB.IN
= Function Blocks Input
KEY.U
=
replica UP button
KEY.D
=
replica DOWN button
KEY.F
=
replica F button
