Page #72 background imageLoading...
Page #72 background image
80208G_MHW_650-1250-1350_01-2017_ENG
70
4. CONFIGURATION
4.8.1. t.SPr - Selecting type of remote setpoint input
Acronym Scrolling message Submenu Attributes
t.SPr DEFINITION OF REMOTE SETPOINT I.SPR R W
The parameter shows and sets the type of remote setpoint input.
Unit of measurement: -
Options: 20MA = Current input in 0...20 mA
4-20M = Current input in 4...20 mA
10V = Voltage input in 0...10 V
2-10V = Voltage input in 2...10 V
1V = Voltage input in 0...1 V
C.20MA = Current input 0...20 mA with user calibration
C.4-20 = Current input 4...20 mA with user calibration
C.10V = Current input 0...10 V with user calibration
C.2-10 = Current input 2...10 V with user calibration
C.1V = Current input 0...1 V with user calibration
4.8.2. F.SPr - Selecting remote setpoint input function
Acronym Scrolling message Submenu Attributes
F.SPr FUNCTION OF REMOTE SETPOINT I.SPR R W
The parameter shows and sets the function assigned to the remote setpoint input.
Unit of measurement: -
Options: NONE = Display only
SETP = Remote setpoint of Process Value (PV)
POWER = Remote setpoint of Power
RST.PW = Reset power
4.8.3. Lin.S - Selecting linearization type
Acronym Scrolling message Submenu Attributes
Lin.S CUSTOM LINEARIZATION I.SPR R W
The parameter shows and sets the type of linearization used.
Unit of measurement: -
Options: NONE = No linearization is applied
32.STP = 32-step linearization defined on LINRZ menu is applied
4.POIN = 4-point linearization defined on LINRZ menu is applied
4.8.4. FILT.S - Filtro digitale
Acronym Scrolling message Submenu Attributes
FILT.S DIGITAL FILTER I.SPR R W
The parameter shows and sets the value of the digital filter time constant.
Unit of measurement: -
Options: 0.00...20.00
