gefran 650 User Manual

80208G_MHW_650-1250-1350_01-2017_ENG
29
2.4.5. Digital inputs
2.4.6. Serial line
2.4.7. CT Inputs
+
-
Output Out 2 - logic
19
20
8
7
Logic 24 V
(10 V to 20 mA)
+
-
L
+V
41
42
43
44
45
46
Digital inputs
COM
IN1
IN2
IN3
IN4
IN5
Digital inputs
NPN 24 V, 4,5 mA
19
20
10
9
23
24
NO
C
Output Out 3 - 5 A relay
5 A relay 250 VAC / 30 VDC
41
42
43
44
45
46
Digital inputs
COM
IN1
IN2
IN3
IN4
IN5
PNP digital inputs
+12/24 V max 3,6 mA
GND
36
35
34
33
32
31
CT1, CT2 inputs
Current transformer
50 mAac, 10 Ω, 50/60 Hz
Second current transformer
for 2-phase / 3-phase load
CT1
~
~
CT2
~
~
37
38
39
40
C
NO
Output Out 4 – 5 A relay
5 A Relay
250 VAC / 30 VDC
41
42
43
44
45
46
Digital inputs
COM
IN1
IN2
IN3
IN4
IN5
Digital inputs voltage-free contact
2. INSTALLATION
Triac 75...264VAC
max 1A
Output Out 4 –Triac
37
38
39
40
~
~
L
Fuse
Serial line
RS485 2-wires
7
8
9
46
47
48
A (Data -)
B (Data +)
Serial line
