16
1.4.2. Drilling dimensions and templates
48 mm
1.89 in
108.6 mm
4.28 in
96 mm
3.78 in
80 mm
3.15 in
92 mm
3.64 in
115 mm
4.53 in
0.39
in
10 mm
70 mm
2.76 in
45 mm
1.78 in
+ 0.6
- 0.0
+ 0.8 - 0.0
Figure 4 - 1250 drilling dimensions and templates
1. GENERAL DESCRIPTION
