45
4.3. Legend for submenus and parameters
The purposes and characteristics of submenus and parameters are described and summarized in the following tables.
4.3.1. Submenu
1. Acronym of submenu as it appears on controller di-
splay.
2. Text of scrolling message as it appears on controller
display.
3. Password needed to access submenu items.
4. Description of functions that manage submenu
4.3.2. Parameters
1. Acronym of parameter as it appears on controller di-
splay.
2. Text of scrolling message as it appears on controller di-
splay.
3. Submenu to which parameter belongs.
4. Attributes of parameter: R = readable, W = writable.
If only R, the operator or technician can read the para-
meter value but cannot change it.
5. Description of use of parameter, including any warnings
or suggestions.
6. Unit of measurement of value managed by parameter.
The unit of measurement can be unique or depend on
other configuration choices, for example, the unit of me-
asurement of temperature, which can be set in degrees
Centigrade or Fahrenheit. Not all parameters require the
use of units of measurement.
Acronym Scrolling message Password Description
INFO INSTRUMENT STATUS Level 1 Gives information on controller state and HW configuration
1 2 3 4
7. Description of parameter values or information that can
be read or written, as appropriate.
8. Value that the parameter can have. Value can be two
types: discrete or pertaining to an interval of values,
typically numerical. For a discrete value, all possible va-
lues are listed as they appear on the controller display.
For intervals of values, the minimum and maximum pa-
rameter values are shown.
9. Any additional description of value of individual para-
meter.
Acronym Scrolling message Submenu Attributes
Out1 OUTPUT TYPE INFO R
The parameter specifies the type of output 1
Unit of measurement:: -
Options:
RELAY
= Relay output
DIGIT
= 24 V logic output
CONTS
= Continuous output
8 9
6
5
7
1 2 3 4
4. CONFIGURATION
