162 ADV200 • Functions description and parameters list
If set to 7 the datum is assigned engineering units on a 16-bit integer.
If set to 8 the datum is assigned engineering units on a 32-bit integer.
If set to 9, the datum is assigned a 16-bit integer engineering unit format not in real time (5-10ms)
If set to 10 the datum is assigned a 32-bit integer engineering unit format or oat format if the associated pa-
rameter is a oat-type parameter not in real time (5-10ms)
Note! If the sys parameter is not assigned, none of the subsequent fieldbus channels are read, even if programmed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.3.3 4024 Fieldbus M->S1 mon INT32 16 0 0 0 ERW FVS
23.3.7 4034 Fieldbus M->S2 mon INT32 16 0 0 0 ERW FVS
23.3.11 4044 Fieldbus M->S3 mon INT32 16 0 0 0 ERW FVS
23.3.15 4054 Fieldbus M->S4 mon INT32 16 0 0 0 ERW FVS
23.3.19 4064 Fieldbus M->S5 mon INT32 16 0 0 0 ERW FVS
23.3.23 4074 Fieldbus M->S6 mon INT32 16 0 0 0 ERW FVS
23.3.27 4084 Fieldbus M->S7 mon INT32 16 0 0 0 ERW FVS
23.3.31 4094 Fieldbus M->S8 mon INT32 16 0 0 0 ERW FVS
23.3.35 4104 Fieldbus M->S9 mon INT32 16 0 0 0 ERW FVS
23.3.39 4114 Fieldbus M->S10 mon INT32 16 0 0 0 ERW FVS
23.3.43 4124 Fieldbus M->S11 mon INT32 16 0 0 0 ERW FVS
23.3.47 4134 Fieldbus M->S12 mon INT32 16 0 0 0 ERW FVS
23.3.51 4144 Fieldbus M->S13 mon INT32 16 0 0 0 ERW FVS
23.3.55 4154 Fieldbus M->S14 mon INT32 16 0 0 0 ERW FVS
23.3.59 4164 Fieldbus M->S15 mon INT32 16 0 0 0 ERW FVS
23.3.63 4174 Fieldbus M->S16 mon INT32 16 0 0 0 ERW FVS
The value received from the bus is displayed. This parameter must be associated with the src parameter to en-
able the M->S channel.
The user may modify the M->S and by S->M sys parameters. The consistency of the sys with the parameter
assigned to the channel is checked.
A Fieldbus M->S X Mon parameter can only be assigned to a single “src”. If assigned to more than one
src, an error signal is generated during eldbus initialization.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.3.4 4026 Fieldbus M->S1 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.8 4036 Fieldbus M->S2 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.12 4046 Fieldbus M->S3 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.16 4056 Fieldbus M->S4 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.20 4066 Fieldbus M->S5 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.24 4076 Fieldbus M->S6 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.28 4086 Fieldbus M->S7 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.32 4096 Fieldbus M->S8 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.36 4106 Fieldbus M->S9 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.40 4116 Fieldbus M->S10 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.44 4126 Fieldbus M->S11 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.48 4136 Fieldbus M->S12 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.52 4146 Fieldbus M->S13 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.56 4154 Fieldbus M->S14 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.60 4166 Fieldbus M->S15 div FLOAT 1.0 1.0 1000.0 ERW FVS
