ADV200 • Functions description and parameters list 161
23.3.53 4150 Fieldbus M->S14 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.57 4160 Fieldbus M->S15 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.61 4170 Fieldbus M->S16 ipa FBM2SIPA 0 0 20000 RW FVS
Setting of the parameter to associate with the bus channel. The default setting is 0, which means channel not
active.
If the parameter to be connected is a sorg (source), the channel and parameter can also be associated by
modifying the sorg parameter in its menu.
When setting a parameter, the format is also automatically set in the sys parameter.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.3.2 4022 Fieldbus M->S1 sys ENUM Not assigned 0 10 RW FVS
23.3.6 4032 Fieldbus M->S2 sys ENUM Not assigned 0 10 RW FVS
23.3.10 4042 Fieldbus M->S3 sys ENUM Not assigned 0 10 RW FVS
23.3.14 4052 Fieldbus M->S4 sys ENUM Not assigned 0 10 RW FVS
23.3.18 4062 Fieldbus M->S5 sys ENUM Not assigned 0 10 RW FVS
23.3.22 4072 Fieldbus M->S6 sys ENUM Not assigned 0 10 RW FVS
23.3.26 4082 Fieldbus M->S7 sys ENUM Not assigned 0 10 RW FVS
23.3.30 4092 Fieldbus M->S8 sys ENUM Not assigned 0 10 RW FVS
23.3.34 4102 Fieldbus M->S9 sys ENUM Not assigned 0 10 RW FVS
23.3.38 4112 Fieldbus M->S10 sys ENUM Not assigned 0 10 RW FVS
23.3.42 4122 Fieldbus M->S11 sys ENUM Not assigned 0 10 RW FVS
23.3.46 4132 Fieldbus M->S12 sys ENUM Not assigned 0 10 RW FVS
23.3.50 4142 Fieldbus M->S13 sys ENUM Not assigned 0 10 RW FVS
23.3.54 4152 Fieldbus M->S14 sys ENUM Not assigned 0 10 RW FVS
23.3.58 4162 Fieldbus M->S15 sys ENUM Not assigned 0 10 RW FVS
23.3.62 4172 Fieldbus M->S16 sys ENUM Not assigned 0 10 RW FVS
Setting of the format of the datum received on the channel. When the src parameter is programmed, the for-
mat is automatically programmed on the relative sys. If the src parameter is reset to null, the format does not
change. The value of the format can be selected from the following list, according to the parameter selected as
the source:
0 Not assigned
1 Count 16
2 Count 32
3 Fill 16
4 Fill 32
5 Mdplc 16
6 Mdplc 32
7 Eu
8 Eu oat
9 Par 16
10 Par 32
If set to 0 the channel is not assigned.
If set to 1 the datum is assigned a 16-bit count.
If set to 2 the datum is assigned a 32-bit count.
If set to 3 16 bits on the channel are reserved for the datum, not used.
If set to 4 32 bits on the channel are reserved for the datum, not used.
If set to 5 the datum is assigned a 16-bit count used by MDPLC.
If set to 6 the datum is assigned a 32-bit count used by MDPLC.
