170 ADV200 • Functions description and parameters list
3 FL Fw 1, FL Fw 2, FL Fw 3
4 FL Fw 1, FL Fw 2, FL Fw 3, FL Fw 4
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.8.6 5714 FL fault enable src LINK 16 6002 0 16384 ERW FVS
This parameter is used to select the origin (source) of the FL fault enable signal.
The signal to be associated with this function can be selected from the “L_DIGSEL1” selection list.
0 FL fault enable not active (No FastLink alarm signal)
1 FL fault enable active (FastLink alarm signal)
When the drive detects a FastLink fault, it prepares to trigger a “FastLink fault” alarm.
This command is used to select whether an alarm is generated when a fault is detected.
Alarm generation is enabled in the default conguration.
The conguration of the “FL fault enable src” parameter can be changed to control the phases in which alarm
generation is enabled.
For example, by connecting the “FL fault enable src” parameter to “Enable state mon” you can enable gen-
eration of the “FastLink fault” alarm in the phase when the drive is enabled.
In systems where drive the drives are not powered-off simultaneously, some drives detect a FastLink fault and
generate a FastLink alarm.
This parameter is used to disable the alarm at power-off by connecting the “FL fault enable src” parameter to
Enable state mon”.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.8.7 5730 FL Fwd 1 src LINK 16/32BIT 6000 0 16384 ERW FVS
23.8.8 5732 FL Fwd 2 src LINK 16/32BIT 6000 0 16384 ERW FVS
23.8.9 5734 FL Fwd 3 src LINK 16/32BIT 6000 0 16384 ERW FVS
23.8.10 5736 FL Fwd 4 src LINK 16/32BIT 6000 0 16384 ERW FVS
This parameter is used to select the origin (source) of the FL Fw 1 src signal.
The signal to be associated with this function can be selected from the “L_FLWORD” selection list.
On the drive congured as the master, these parameters are used to select the data to be sent to the rst
slave.
On drives congured as slaves, these paramters are used to select the data that the slave must include in the
data frame to replace the data received from the previous drive.
Replacement is disabled in the default conguration. It can be enabled with the PAR 5712 “FL N Fwd slave
chg“ parameter.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.8.11 5830 FL Rev 1 src LINK 16/32BIT 6000 0 16384 ERW FVS
23.8.12 5832 FL Rev 2 src LINK 16/32BIT 6000 0 16384 ERW FVS
Parameter signicant only for Slave drive, indicates what data to insert in rst word to be sent to Master drive
when Slave is interrogated. Selectable values are shown on the L_FLWORD list.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
23.8.13 5750 FL Fwd 1 mon INT32 32BIT 0 0 2^32 ER FVS
23.8.14 5752 FL Fwd 2 mon INT32 32BIT 0 0 2^32 ER FVS
23.8.15 5754 FL Fwd 3 mon INT32 32BIT 0 0 2^32 ER FVS
23.8.16 5756 FL Fwd 4 mon INT32 32BIT 0 0 2^32 ER FVS
23.8.17 5758 FL Fwd 5 mon INT32 32BIT 0 0 2^32 ER FVS
23.8.18 5760 FL Fwd 6 mon INT32 32BIT 0 0 2^32 ER FVS
23.8.19 5762 FL Fwd 7 mon INT32 32BIT 0 0 2^32 ER FVS
23.8.20 5764 FL Fwd 8 mon INT32 32BIT 0 0 2^32 ER FVS
