ADV200 • Functions description and parameters list 175
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.13 4528 MotorOT holdoff ms UINT16 1000 0 30000 RW FVS
Setting of the delay between the signalling of the motor overtemperature alarm MotorOT and enabling of the
alarm. If an alarm condition occurs, the drive will wait for the set time before enabling the alarm. If the alarm is
removed within the set time, the drive will not indicate any alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.14 4530 MotorOT probe ENUM SRC 0 8 ERW FVS
Selection of type of sensor for measuring external temperature. The following can be selected:
0 SRC alarm managed via IPA 4520 MotorOT src
1 Sens An1X alarm managed via PT100/PT1000/NI1000 read by input 1 expansion card (*)
2 Sens An2X alarm managed via PT100/PT1000/NI1000 read by input 2 expansion card (*)
3 KTY84 AnX alarm managed via KTY84 read by dedicated input for cards (*)
4 PTC AnX alarm managed via PTC read by dedicated input for cards (*)
5 KTY84 An1 alarm managed via KTY84 read by analog input 1 of control card
6 KTY84 An2 alarm managed via KTY84 read by analog input 2 of control card
7 PTC An1 alarm managed via PTC read by analog input 1 of control card
8 PTC An2 alarm managed via PTC read by analog input 2 of control card
9 Klixon AnX alarm managed via KLIXON read by dedicated input for cards (*)
10 KTY84 An1X alarm managed via KTY84 read by analog input 1 expansion card (*)
11 KTY84 An2X alarm managed via KTY84 read by analog input 2 expansion card (*)
12 PTC An1X alarm managed via PTC read by analog input 1 expansion card (*)
13 PTC An2X alarm managed via PTC read by analog input 2 expansion card (*)
(*) = EXP-IO-SENS-100-ADV, EXP-IO-SENS-1000-ADV.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.15 4514 MotorOT KTY84 unit ENUM ohm 0 1 ERW FVS
It allows to select the activation “MotorOT” alarm threshold in ohm or degrees Celsius (°C):
0 ohm (IPA 4532 MotorOT thr and IPA 4536 MotorOT mon will be shown in ohm).
1 °C (IPA 4532 MotorOT thr and IPA 4536 MotorOT mon will be shown in °C).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.16 4532 MotorOT thr (*) UINT16 0 0 32767 ERW FVS
Represents the resistance threshold at which the “Motor OT” alarm must trip.
To the IPA 4536 has been associated the “SysMotorOTmon” system variable and It is available for MDPLC
application. This system variable is scaled for 2^16 and it has been dened in Ohm or °C depending on the
selection thru IPA 4514.
(*) The parameter is expressed in counts, ohms or °C depending on the type of sensor selected.
The parameter is expressed in Ohm when selecting PTC An1, PTC An2.
The parameter is expressed in Ohm or °C when selecting KTY84 An1, KTY84 An2.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.17 4536 MotorOT mon (*) INT16 16/32 0 0 32767 ER FVS
Represents the measurement monitor of the sensor.
(*) The parameter is expressed in counts, ohms or °C depending on the type of sensor selected.
The parameter is expressed in Ohm when selecting PTC An1, PTC An2.
The parameter is expressed in Ohm or °C when selecting KTY84 An1, KTY84 An2.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
24.18 4540 Overspeed threshold rpm INT32 CALCI 0 CALCI RW FVS
Setting of the threshold above which the overspeed alarm Overspeed is enabled.
