gefran ADV200 User Manual

ADV200 • Functions description and parameters list 193
- 1690 An inp 2X err mon BIT 16 0 0 0 ER
This parameter contains the signal of possible disconnection of the related input from the optional board.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2388 Torque ref nofilter perc FLOAT 16 0.0 0.0 0.0 ER
The torque control reference current without lter is displayed (in Flux vector OL and eld-oriented vector mode).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2396 Torque nofilter perc FLOAT 16 0.0 0.0 0.0 ER
Monitoring of the actual torque reference without lters.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3006 Speed ratio out mon rpm INT16 16 0 0 0 ER
This parameter displays the value of the speed ratio used by the “Speed draw” function (speed ratio).
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2392 Torque ref 1 mon perc FLOAT 16/32 0.0 -300.0 300.0 ERW
The total value of torque reference 1 is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3180 Brake control mon rpm INT16 16 0 0 1 ER
This parameter displays the status of the brake command.
0 Brake closed
1 Brake open
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3192 Brake open thr mon perc FLOAT 0 0.0 0 ERS
Brake opening threshold value. Only if Hoist mode 2 has been selected.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3214 Motor overload trip BIT 16 0 0 1 ER
This signal is active when the drive is in the motor overload alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3262 Bres overload trip BIT 16 0 0 1 ER
This signal is active when the drive is in the braking resistor overload alarm condition.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3374 Vf catch out INT32 16 0 0 0 ER
The voltage applied during capture on-the-y of the motor in Vf mode is displayed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
3442 Powerloss rampdown BIT 16 0 0 1 ER
This parameter indicates the status of the Powerloss function deceleration ramp
0 Powerloss function deceleration ramp not ended
1 Powerloss function deceleration ramp ended
The signal is enabled at the end of the Powerloss function deceleration ramp.
The signal is disabled at different times depending on the Powerloss mode setting.
