Page #194 background image
194 ADV200 • Functions description and parameters list
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 3446 Powerloss nextratio INT32 32 0 0 0 ER
This parameter gives the ratio between the motor speed and the speed reference.
For machines with several drives, line synchronisation can be achieved by connecting the Powerloss mode
output of the master to the Speed ratio src input of the slave drives. The master => slave connection can be
achieved via analog signals or eldbus.
The value 2^30 corresponds to a ratio of 1.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 3448 Powerloss nextactive BIT 16 0 0 1 ER
This parameter indicates the status of the Powerloss function
0 Powerloss not enabled
1 Powerloss enabled
The function is enabled when there is a power failure.
The function is disabled at different times depending on the Powerloss mode setting.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 3480 Vdc ctrl ramp freeze BIT 16 0 0 1 ER
This parameter displays when the deceleration ramp block is requested during the Vdc control function.
0 VdcCtrl function not enabled
1 VdcCtrl function enabled
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 3512 Drv thr overtemp mon UINT32 0 0 1 ER
Signals that the threshold set in PAR 3504 Drv temp thr has been exceeded.
0 Threshold not exceeded
1 Threshold exceeded
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 3514 Mot thr overtemp mon UINT32 0 0 1 ER
Signals that the threshold set in PAR 3506 Mot temp thr has been exceeded.
0 Threshold not exceeded
1 Threshold exceeded
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
- 4372 DS402 status word UINT16 16 0 0 65535 ER
This parameter displays the status word according to the DS402 prole. For more information reference should
be made to the eldbus manual.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4394 PFdrv status word 1 UINT16 16 0 0 65535 ER
This parameter displays the status word 1 according to the Prodrives prole. For more information reference
should be made to the eldbus manual.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4396 PFdrv status word 2 UINT16 16 0 0 65535 ER
This parameter displays the status word 2 according to the Prodrives prole. For more information reference
should be made to the eldbus manual.
