gefran ADV200

ADV200 • Troubleshooting 197
Bit Description
6 1 = MultiOvercurr active
7 1 – MultiDesat active
8 1 = Heatsink OT active
9 1 = Heatsink lin OT active
10 1 = Air OT active
11 1 = Motor OT active
12 1 = Drive overload active
13 1 = Motor overload active
14 1 = Bres overload active
15 1 = Phase loss active
16 1 = Opt bus fault active
17 1 = Opt 1 I/O fault active
18 1 = Opt 2 I/O fault active
19 1 = Opt enc fault active
20 1 = External fault active
21 1 = Fbk loss active
22 1 = Overspeed active
23 1 = Ref loss active
24 1 = Emg stop alarm active
25 1 = Power down active
26 1 = not used
27 1 = not used
28 1 = not used
29 1 = not used
30 1 = not used
31 1 = not used
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4842 Alarm hi state UINT32 32 0 0 0 ER
This parameter displays the state of alarms 33...64 of the drive.
Bit Description
0 1 = PLC 1 fault active
1 1 = PLC 2 fault active
2 1 = PLC 3 fault active
3 1 = PLC 4 fault active
4 1 = PLC 5 fault active
5 1 = PLC 6 fault active
6 1 = PLC 7 fault active
7 1 = PLC 8 fault active
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
5800 FL Fwd 1 inv mon INT32 32BIT 0 0 0 ER
5802 FL Fwd 2 inv mon INT32 32BIT 0 0 0 ER
5804 FL Fwd 3 inv mon INT32 32BIT 0 0 0 ER
5806 FL Fwd 4 inv mon INT32 32BIT 0 0 0 ER
5808 FL Fwd 5 inv mon INT32 32BIT 0 0 0 ER
5810 FL Fwd 6 inv mon INT32 32BIT 0 0 0 ER
5812 FL Fwd 7 inv mon INT32 32BIT 0 0 0 ER
5814 FL Fwd 8 inv mon INT32 32BIT 0 0 0 ER
These parameters are not used on the master drive.
On the slave drive these parameters show the value received from the previous drive. The “ Inv” parameters
enable the value received to be used with the opposite sign, without changing any of the data sent to subse-
quent slaves.
These parameters are available in the “src” analog parameter selection lists.
