ADV200 • Functions description and parameters list 21
DC power supply
Drive family 380V..480V
Mains voltage
Drive family 690V
Mains voltage
3 750 V (380-480V) 460 V N/A
10 675 V (690V) N/A 500 V (
if compatible with the size, otherwise N/A
)
11 810 V (690V) N/A 575 V (
if compatible with the size, otherwise N/A
)
12 935 V (690V) N/A 690 V
13 1120 V (690V) N/A 690 V
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.7 450 Undervoltage V FLOAT CALCF CALCF CALCF ERWZS FVS
Setting of the drive minimum operating voltage. The maximum and minimum default values are calculated auto-
matically by the drive according to the value set in parameter 560 Mains voltage, as shown in the table below.
Table of undervoltage limits
Mains voltage Def Min Max
0 None (Vdc) (Vdc) (Vdc)
1 230 V 225 200 282
2 380 V 372 330 466
3 400 V 392 330 490
4 415 V 407 360 509
5 440 V 431 382 539
6 460 V 451 400 564
7 480 V 470 417 588
8 500 V 490 434 613
9 575 V 563 500 705
10 690 V 676 600 846
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.8 562 Switching frequency ENUM SIZE SIZE SIZE ERWS FVS
Setting of the switching frequency value in kHz. The maximum value that can be set depends on the size of the drive.
0 1 kHz
1 2 kHz
2 4 kHz
3 6 kHz
4 8 kHz
5 10 kHz
6 12 kHz
7 16 kHz
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.9 564 Ambient temperature ENUM 40 degC 0 1 ERWZ FVS
Setting of the ambient temperature value. This parameter is used to set the output current derating factor (1%
for every °C above 40°C).
0 40 degC The inverter is capable of delivering direct current continuously with ambient temperatures of up
to 40°C.
1 50 degC The inverter is capable of delivering direct current continuously with ambient temperatures of up
to 50°C.
If the value is set to 1 the drive output current will be 10% less than the rated current at 40°C.
Installation altitude above
sea level
Output Current derating factor at Ambient Temperature of:
20°C 25°C 30°C 35°C 40°C 45°C 50°C
0 … 1000 m 100% 85% 90%
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.10 566 Drive overload mode ENUM Heavy duty 1 2 ERWZ FVS
Setting of the current overload that can be supplied by the drive, depending on the application.
