22 ADV200 • Functions description and parameters list
1 Heavy duty
2 Light duty
Set Heavy duty when a large overload is requested:
• (asynchronous motor control) the drive can supply 180% of the rated current for 0,5 seconds and 150%
for 1 minute every 5 minutes.
• (synchronous motor control) the drive can supply 200% of the rated current for 3 seconds and 160% for 1
minute every 5 minutes,
Select Light duty to enable the drive to deliver a current of 110% of the rated current for 1 minute every 5
minutes.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.11 568 Switching freq mode ENUM Costant 0 1
ERWZS
FVS
Setting of the switching frequency operating mode.
The factory switching frequency setting is 4 kHz for motors between 2.2 kW and 37 kW (the factory switching
frequency setting for smaller drives is 8kHz); this value may result in increased noise. Setting a higher switch-
ing frequency will increase drive losses and thus increase the heatsink temperature, but it will also reduce
noise. To combine the advantages of both settings, with the ADV drive the heatsink temperature can be control-
led by reducing the switching frequency if it increases.
0 Costant
1 Variable
If set to Constant, the switching frequency is xed and set with the Switching freq mode parameter according
to the size of the drive. If the selected switching frequency is higher than the default value, the drive output cur-
rent is derated.
If set to Variable, the switching frequency is set to 8 kHz (for sizes between 2.2 kW and 37 kW / lower values
are dened for more powerful drives) and the drive heat sink temperature and output frequency values are also
controlled. If the heat sink temperature exceeds a given threshold (which depends on the size of the drive) or
the output frequency falls to less than 5 Hz, the switching frequency is automatically reduced to 4 kHz (again
considering sizes of between 2.2 kW and 37 kW), to avoid any derating of the output current value. (When the
output frequency exceeds 7 Hz the switching frequency is brought back to 8 kHz). The switching frequency is
reduced in a single step.
With this setting the switching frequency value selected in the Switching frequency parameter is inef-
fective.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.12 454 Chopper ON V FLOAT CALCF CALCF CALCF ERWZS FVS
Corresponding to the threshold of activation of the braking resistor. It is so possible to increase this value just
below the Overvoltage threshold level (ADV200 -4: 820 Vdc, ADV200 -6: 1192 Vdc).
Parameter’s range are dened thru IPA 560 Mains voltage setting
Note! If Mains voltage is set at the maximum possible value, the activation threshold of the braking resistor can only assume the max
value and can not be changed.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
4.13 570 Password UINT32 0 0 99999 ERW FVS
You can enter a password to protect the parameters from unauthorized tampering: the password can consist
of a combination of a maximum of any 5 gures that can be selected by the user. All parameters are locked,
except this one and Save parameters.
After entering the password, press the E key once to enter it into the memory and again to enable it (= Enabled
is displayed to indicate that the password is enabled).
So that the password remains valid even after switching the unit off and then switching it back on, save it using
the Save parameters command.
When the password is enabled any attempts to modify a parameter are blocked and the Password enabled
message is displayed.
To disable the password, enter the Password parameter (572) in the DRIVE CONFIG menu.
