ADV200 • Messages 213
Index Error message shown
on the display
Sub-code Description
8
Internal calculation error concerning IGBT control
Solution: Perform autotuning once more, if the problem persists, contact the Gefran technical
support centre.
9
The drive has measured a stator resistance value exceeding the set limit.
Solution: contact the Gefran technical support centre.
10
The drive has measured a stator resistance value below the set limit.
Solution: contact the Gefran technical support centre.
11-12
Measurement of DTL internal compensation voltage outside accepted range.
Solution: check connection between drive and motor.
If correct, the drive is faulty, contact the Gefran technical support centre.
13-14
Measurement of DTS internal voltage outside accepted range.
Solution: check connection between drive and motor.
If correct, the drive is faulty, contact the Gefran technical support centre.
15 - 16 -17
LS leakage inductance value outside accepted range.
Solution: Perform autotuning once more, if the problem persists, contact the Gefran technical
support centre.
18-19
Measurement of Im magnetising current outside accepted range.
Solution: Perform autotuning once more, if the problem persists, contact the Gefran technical
support centre.
20-21
Measurement of Rr rotor resistor outside accepted range.
Solution: Perform autotuning once more, if the problem persists, contact the Gefran technical
support centre.
Solution: If the message appears with a value other than 0, follow the instructions supplied for each particular case
and repeat Autotune. This should be performed using the wizard function available from the keypad (STARTUP WIZ-
ARD) and the Tool software on the PC.
Pay attention to all motor plate data parmaeters, especially:
- Rated speed, Motor rated speed in rpm.
- Rated frequency, Motor rated frequency in Hz
- Pole pairs, Motor pole pairs
Take care not to set the Rated speed parameter to the synchronous speed. The value of the Rated speed parameter
must be less than: [(Rated frequency * 60) / Pole pairs].
If the problem persists even after following the instructions supplied, confirm the values of the motor plate data param-
eters, execute the Take parameters command but not Autotune.
6 Power config
Condition: may occur during recognition of power cards. If this message is displayed, it is not possible to drive the
motor.
0020H-32 The power card is configured for a drive that is incompatible with the regulation card
0021H-33 The configuration of the power card is not compatible with the regulation card
0017H-23 The configuration required is not available on the power card
Solution: Download the correct configuration on the power card
7 Save par failed Condition: during transfer of the parameters from the drive to the memory of the keypad
0H-0 Communication error
0025H-37 The data saved on the keypad are not valid
0026H-38 Incompatible drive series
0027H-39 Incompatible software version
0028H-40 Incompatible drive size
0029H-41 Error during saving of parameters on the drive
Solution:
8 Load par failed Condition: during transfer of the parameters from the memory of the keypad to the drive
9 Load par incomplete 0H-0 Communication error
0025H-37 The data saved on the keypad are not valid.
No parameter is transferred from the keypad to the drive
0026H-38 Incompatible control type.
No parameter is transferred from the keypad to the drive
0027H-39 Incompatible software version.
All the parameters present in the memory of the keypad have been transferred to the drive. The
set of parameters transferred refers to a drive with a different firmware version; therefore, certain
parameters may not be updated.
0028H-40 Incompatible control type.
All the parameters present in the memory of the keypad (excluding those that depend on the size
of the drive), have been transferred to the drive. The parameters that depend on size maintain
their original value.
