214 ADV200 • Block Diagrams
Index Error message shown
on the display
Sub-code Description
0029H-41 Error during saving of parameters on the drive.
All the parameters present in the memory of the keypad have been transferred to the drive. The
transfer of one or more parameters has caused an “out of range” error, or one or more parameters
does not exist. At the end of transfer, one or more parameters may not have been updated.
002AH-42 PLC application release and version not compatible.
All parameters in the keypad memory have been transferred to the drive.
The transferred set of parameters relates to a drive with a PLC application in which the version
and release of the application are different. As a result some of the PLC application parameters
may not be updated.
002BH-43 PLC application not compatible.
All the parameters in the keypad memory except those relating to the PLC applciation have been
transferred to the drive.
The transferred set of parameters relates to a drive with a different PLC application. As a result
none of the PLC application parameters are updated.
Solution: Recover a set of parameters from a compatible drive (model and size)
10 Options config error Condition: may occur at drive start-up, during recognition of the optional cards installed
0001H-1 Non-permissible optional card in slot 1
0002H-2 Non-permissible optional card in slot 2
0004H-4 Non-permissible optional card in slot 3
0010H-16 Conflict slot 1 with slot 2
0020H-32 Conflict slot 1 with slot 3
0040H-64 Conflict slot 2 with slot 3
Solution: Remove the optional cards from the incorrect slots and insert them in the correct slots
11 Load def plc
Condition: may occur during loading of the parameter database saved in the Flash of the Mdplc application
Normally appears at initial power-on after downloading a new application.
If this message is displayed when the drive is already operating, this means that a problem has occurred in the param-
eter database saved in Flash.
If this message appears the drive restores the default database, i.e. the one that was downloaded.
0001H-1 The database saved is not valid
Solution: Set the parameters to the value required and perform Save parameter
12 Plc cfg error
Condition: may occur during loading of the Mdplc application
The Mdplc application present on the drive is not run.
0004H-4 The application downloaded has a different Crc on DataBlock and Function table
0065H-101
The application downloaded has an invalid identifier (Info)
0066H-102
The application downloaded has an incorrect task number (Info)
0067H-103
The application downloaded has an incorrect software configuration
0068H-104
The application downloaded has a different Crc on DataBlock and Function table
0069H-105
A Trap error or System error has occurred.
The drive automatically performs a Power-up operation.
The application is not run.
See in Alarm List for further information regarding the error occurred
006AH-106
The application downloaded has an incorrect identifier (Task)
006BH-107
The application downloaded has an incorrect task number (Task)
006CH-108
The application downloaded has an incorrect Crc (Tables + Code)
Solution: Remove the Mdplc application or download a correct Mdplc application
13 Plc 1
Reserved messages and dedicated to the PLC application. See the application manual.
14 Plc 2
15 Plc 3
16 Plc 4
17 Option bus fault
Condition: this may occur when the drive is turned on, during fieldbus card setup. Error during configuration or com-
munication error.
XXX0H-X If the first digit to the left of “H” in the alarm sub-code is 0, the error regards a communication
problem.
XXX0H-X If the first digit to the left of “H” in the alarm sub-code is other than 0, the error regards a configu-
ration problem.
Solution: For configuration errors, check the configuration of the bus communication, type of bus, baudrate, address,
parameter setting.
For communication errors, check wiring, termination resistors, disturbance immunity, timeout settings.
For further details, please refer to the user guide for the specific bus.
18 Key failed
Condition: this may occur when powering the drive, if the incorrect enable key is inserted for a given firmware func-
tion.
