gefran ADV200

254 ADV200 • Parameters List
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.62 5420 Analog inp 5Ext mon INT16 16 0 -32768 32767 ER FVS
14.63 5422 Analog inp 6Ext mon INT16 16 0 -32768 32767 ER FVS
14.64 5424 Analog inp 7Ext mon INT16 16 0 -32768 32767 ER FVS
14.65 1586 Sensor inp X type ENUM None 0 3 ERW FVS
0 None
1 Klixon
2 KTY84
3 PTC
15 - ANALOG OUTPUTS
15.1 1800 Analog out 1 src LINK 16/32 6000 0 16384 RW FVS
L_ANOUT
15.2 1802 Analog out 2 src LINK 16/32 6000 0 16384 RW FVS
L_ANOUT
15.3 1808 Analog out 1 scale FLOAT 1.0 -10.0 10.0 RW FVS
15.4 1810 Analog out 2 scale FLOAT 1.0 -10.0 10.0 RW FVS
15.5 1816 Analog out 1 mon cnt INT16 0 0 0 ER FVS
15.6 1818 Analog out 2 mon cnt INT16 0 0 0 ER FVS
15.7 1824 An out 1 absolute ENUM Disable 0 1 ERW FVS
0 Disable
1 Enable
15.8 1826 An out 2 absolute ENUM Disable 0 1 ERW FVS
0 Disable
1 Enable
15.9 1832 Analog out 1 min cnt INT16 -16384 -32768 +32767 ERW FVS
15.10 1834 Analog out 1 max cnt INT16 16384 -32768 +32767 ERW FVS
15.11 1840 Analog out 2 min cnt INT16 -16384 -32768 +32767 ERW FVS
15.12 1842 Analog out 2 max cnt INT16 16384 -32768 +32767 ERW FVS
15.13 1848 Analog out 2 type ENUM -10V..+10V 0 2 ERW FVS
0 0..20mA
1 4..20mA
2 -10V..+10V
15.14 1850 Analog out 1X src LINK 16/32 6000 0 16384 RW FVS
L_ANOUT
15.15 1852 Analog out 2X src LINK 16/32 6000 0 16384 RW FVS
L_ANOUT
15.16 1858 Analog out 1X scale FLOAT 1.0 -20.0 20.0 RW FVS
15.17 1860 Analog out 2X scale FLOAT 1.0 -20.0 20.0 RW FVS
15.18 1866 Analog out 1X mon cnt INT16 0 0 0 ER FVS
15.19 1868 Analog out 2X mon cnt INT16 0 0 0 ER FVS
15.20 1874 An out 1X absolute ENUM Disable 0 1 ERW FVS
0 Disable
1 Enable
15.21 1876 An out 2X absolute ENUM Disable 0 1 ERW FVS
0 Disable
1 Enable
15.22 1882 Analog out 1X min cnt INT16 -16384 -32768 +32767 ERW FVS
15.23 1884 Analog out 1X max cnt INT16 16384 -32768 +32767 ERW FVS
15.24 1886 Analog out 1X type ENUM -10V..+10V 0 3 ERW FVS
0 0..20mA
1 4..20mA
2 -10V..+10V
3 0..10V
15.25 1890 Analog out 2X min cnt INT16 -16384 -32768 +32767 ERW FVS
