gefran ADV200

ADV200 • Parameters List 255
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
15.26 1892 Analog out 2X max cnt INT16 16384 -32768 +32767 ERW FVS
15.27 1898 Analog out 2X type ENUM -10V..+10V 0 3 ERW FVS
0 0..20mA
1 4..20mA
2 -10V..+10V
3 0..10V
15.28 5460 Dig Analog out 0 ext INT16 16 0 -32768 32767 ERW FVS
15.29 5462 Dig Analog out 1 ext INT16 16 0 -32768 32767 ERW FVS
15.30 5464 Dig Analog out 2 ext INT16 16 0 -32768 32767 ERW FVS
15.31 5466 Dig Analog out 3 ext INT16 16 0 -32768 32767 ERW FVS
15.32 5468 Dig Analog out 4 ext INT16 16 0 -32768 32767 ERW FVS
15.33 5470 Dig Analog out 5 ext INT16 16 0 -32768 32767 ERW FVS
15.34 5472 Dig Analog out 6 ext INT16 16 0 -32768 32767 ERW FVS
15.35 5474 Dig Analog out 7 ext INT16 16 0 -32768 32767 ERW FVS
16 - MOTOR DATA
16.1 2000 Rated voltage V FLOAT SIZE 50.0 690.0 RWZS FVS
16.2 2002 Rated current A FLOAT SIZE 0.3 2200.0 RWZS FVS
16.3 2004 Rated speed rpm FLOAT SIZE 10.0 32000.0 RWZS FVS
16.4 2006 Rated frequency Hz FLOAT SIZE 10.0 1000.0 RWZS FVS
16.5 2008 Pole pairs UINT16 SIZE 1 20 RWZS FVS
16.6 2010 Rated power kW FLOAT SIZE 0.05 2000.0 RWZS FVS
16.7 2012 Rated power factor FLOAT SIZE 0.6 0.95 RWZS FVS
16.8 2020 Take parameters BIT 0 0 1 RWZ FVS
16.9 2022 Autotune rotation BIT 0 0 1 RWZ FVS
16.10 2024 Autotune still BIT 0 0 1 RWZ FVS
16.11 2026 Autotune mode ENUM Reduced 0 1 ERWZ FVS
0 Reduced
1 Extended
16.12 2028 Take par status ENUM Required 0 0 R FVS
0 Required
1 Done
16.13 2030 Autotune status ENUM Required 0 0 R FVS
0 Required
1 Done
16.14 2050 Measured Rs ohm FLOAT CALCF 0.0005 200.0 ERWS FVS
16.15 2052 Measured DTL V FLOAT 0.0 0.0 100.0 ERWS FVS
16.16 2054 Measured DTS V/A FLOAT 0.0 0.0 100.0 ERWS FVS
16.17 2056 Measured Lsig mH FLOAT CALCF 0.01 700 ERWS FVS
16.18 2058 Measured ImN A FLOAT CALCF 0.1 1500.0 ERWS FVS
16.19 2060 Measured ImX A FLOAT CALCF 0.0 0.0 ERWS FVS
16.20 2062 Measured FlxN Wb FLOAT CALCF 0.05 10.0 ERWS FVS
16.21 2064 Measured FlxX Wb FLOAT CALCF 0.0 0.0 ERWS FVS
16.22 2066 Measured P1 FLOAT 0.5 0.0 1.0 ERWS FVS
16.23 2068 Measured P2 FLOAT 9.0 3.0 18.0 ERWS FVS
16.24 2070 Measured P3 FLOAT 0.87 0.0 1.0 ERWS FVS
16.25 2072 Measured Rr ohm FLOAT CALCF 0.0005 200.0 ERWS FVS
16.26 2078 Take tune parameters BIT 0 0 1 ERWZ FVS
17 - ENCODER
17.1 - ENCODER/ENCODER CONFIG
17.1.1 5310 Encoder sel src LINK 16 6000 0 16384 ERW FVS
