ADV200 • Parameters List 257
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
17.3.4 5106 Encoder 2 repetition ENUM No division 0 3 ERWZ FVS
0 No division
1 Divide 2
2 Divide 4
3 Divide 8
17.3.5 5108 Encoder 2 signal Vpp V FLOAT 1.0 0.8 1.2 ERWZ FVS
17.3.6 5110 Encoder2signal check ENUM Check A-B 0 3 ERWZ FVS
0 Check disabled
1 Check A-B
2 Check A-B-Z
4 Check A-B-SE
17.3.7 5112 Encoder 2 SSI clocks UINT16 13 11 25 ERWZ FVS
17.3.8 5114 Encoder2SSI pos bits UINT16 13 11 25 ERWZ FVS
17.3.9 5182 Encoder2 ENDAT clock ENUM 1 MHz 0 1 ERWZ FVS
0 1 MHz
1 500 kHz
17.3.10 5130 Encoder 2 direction ENUM Not inverted 0 1 ERWZ FVS
0 Not inverted
1 Inverted
17.3.11 5132 Encoder 2 mode ENUM None CALCI CALCI ERWZ FVS
0 None
1 Digital FP
2 Digital F
3 Sinus
4 Sinus SINCOS
5 Sinus ENDAT
6 Sinus SSI
7 Sinus HIPER
8 Resolver
9 Abs SINCOS
10 ENDAT
11 SSI
17.3.12 5134 Encoder2speed filter ms FLOAT 2.0 0.125 20.0 ERW FVS
17.3.13 5150 Encoder 2 speed rpm INT16 16/32 0 0 0 ER FVS
17.3.14 5162 Encoder 2 position cnt UINT16 16 0 0 0 ER FVS
17.3.15 5360 Encoder 2 state UINT16 0 0 0 ER FVS
17.3.16 5362 Encoder 2 err code UINT32 0 0 0 ER FVS
17.4 - ENCODER/ENCODER 3
17.4.1 5200 Encoder 3 pulses ppr UINT16 1024 128 32768 ERWZ FVS
17.4.2 5204 Encoder 3 input cfg ENUM TTL 0 1 ERWZ FVS
0 HTL
1 TTL
17.4.3 5210 Encoder3signal check ENUM Check A-B 0 3 ERWZ FVS
0 Check disabled
1 Check A-B
2 Check A-B-Z
4 Check A-B-SE
17.4.4 5230 Encoder 3 direction ENUM Not inverted 0 1 ERWZ FVS
0 Not inverted
1 Inverted
17.4.5 5262 Encoder 3 position cnt UINT16 16 0 0 0 ER FVS
17.4.6 5370 Encoder 3 state UINT16 0 0 0 ER FVS
17.4.7 5372 Encoder 3 err code UINT32 0 0 0 ER FVS
