ADV200 • Parameters List 261
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.2 - FUNCTIONS/DROOP
22.2.1 3052 Droop ref src LINK 16/32 6000 0 16384 ERW F_S
L_LIM
22.2.2 3060 Droop gain perc FLOAT 0.0 0.0 100.0 ERW F_S
22.2.3 3062 Droop filter ms UINT16 10 1 100 ERW F_S
22.2.4 3064 Droop limit rpm INT16 16/32 30 0 CALCI ERWZ F_S
22.2.5 3070 Droop out mon rpm INT16 16/32 0 0 0 ER F_S
22.3 - FUNCTIONS/INERTIA COMP
22.3.1 3100 Inertia comp kgm2 FLOAT 0.0 0.0 100.0 ERWS F_S
22.3.2 3102 Inertia comp filter ms UINT16 30 1 100 ERW F_S
22.3.3 3104 Inertia comp mon perc FLOAT 16/32 0.0 0.0 0.0 ER F_S
22.4 - FUNCTIONS/DC BRAKING
22.4.1 3150 DC braking cmd src LINK 16 6000 0 16384 ERW FVS
L_DIGSEL2
22.4.2 3152 DC brake mode ENUM Off 0 7 ERWZ FVS
0 Off
1 Stop
2 Cmd
3 Cmd&Stop
4 Start
5 Start&Stop
6 Cmd&Start
7 Cmd&Start&Stop
22.4.3 3154 DC brake delay s FLOAT 0.5 0.00 30.0 ERW FVS
22.4.4 3156 DC brake duration s FLOAT 1.0 0.01 30.0 ERW FVS
22.4.5 3158 DC brake current perc FLOAT 50.0 0.0 150.0 ERW FVS
22.4.6 3160 DC brake state ENUM 16 Not active 0 1 ER FVS
0 Not active
1 Active
22.5 - FUNCTIONS/AC BRAKING
22.5.1 2484 AC braking ENUM Disable 0 1 ERWZ _V_
0 Disable
1 Enable
22.5.2 2486 AC brake Kp V/A FLOAT CALCF 0.0 100.0 ERWS _V_
22.5.3 2488 AC brake Ti ms FLOAT CALCF 1.0 1000.0 ERWS _V_
22.5.4 2478 AC brake active ref perc FLOAT -2 -10 10 ERWS _V_
22.6 - FUNCTIONS/MOTOR OVERLOAD
22.6.1 3200 Motor ovld enable BIT 0 0 1 ERW FVS
22.6.2 3202 Motor ovld factor perc FLOAT 150.0 100.0 300.0 ERWS FVS
22.6.3 3204 Motor ovld time s FLOAT 30.0 10.0 300.0 ERWS FVS
22.6.4 3206 Motor service factor perc FLOAT 100.0 25.0 200.0 ERWS FVS
22.6.5 3216 Motor fan type ENUM Servo fan 0 1 ERW FVS
0 Auto fan
1 Servo fan
22.6.6 3218 Motor derat factor perc FLOAT 50.0 0.0 100.0 ERWS FVS
22.7 - FUNCTIONS/BRES OVERLOAD
