262 ADV200 • Parameters List
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.7.1 3250 Bres control BIT 0 0 1 ERWZS FVS
22.7.2 3252 Bres value ohm FLOAT SIZE 3.0 1000.0 ERWS FVS
22.7.3 3254 Bres cont power kW FLOAT SIZE 0.1 100.0 ERWS FVS
22.7.4 3256 Bres overload factor FLOAT SIZE 1.5 10.0 ERWS FVS
22.7.5 3258 Bres overload time s FLOAT SIZE 0.5 50.0 ERWS FVS
22.7.6 3272 Bres enable src LINK 16 6002 0 16384 ERW FVS
L_DIGSEL1
22.7.7 3274 Bres enable inv BIT 0 0 1 ERW FVS
22.8 - FUNCTIONS/DOUBLE PAR SET
22.8.1 3300 Par set enable ENUM Disable 0 1 ERW FVS
0 Disable
1 Enable
22.8.2 3302 Par set select src LINK 16 6000 0 16384 ERWZ FVS
L_DIGSEL2
22.8.3 3304 Par set select mon ENUM 16 Set 0 0 0 ER FVS
0 Set 0
1 Set 1
22.8.4 3306 Par set 0 to 1 copy BIT 0 0 1 ERW FVS
22.9 - FUNCTIONS/SPEED CAPTURE
22.9.1 3350 Speed capture ENUM Disable 0 2 ERW FV_
0 Disable
1 Alarm restart
2 Enable&restart
22.9.2 3364 Vf catch start freq Hz FLOAT CALCF -500.0 500.0 ERWZ _V_
22.9.3 3366 Vf catch enable dly ms UINT16 CALCF 10 30000 ERWZ _V_
22.9.4 3368 Vf catch reflux time s FLOAT CALCF 0.1 100.0 ERW _V_
22.9.5 3370 Vf catch Kp gain Hz/A FLOAT CALCF 0.0 100.0 ERW _V_
22.9.6 3372 Vf catch Ti time ms UINT16 CALCI 10 10000 ERW _V_
22.9.7 3376 Vf catch lastref dly ms UINT16 0 0 30000 ERWZ _V_
22.9.8 3388 Vf catch search volt perc UINT16 10 1 20 ERW _V_
22.9.9 3390 Vf catch search curr perc FLOAT 0.6 -1.0 10.0 ERWS _V_
22.9.10 3392 Iactive filter ms FLOAT 20.0 1.0 150.0 ERWZ _V_
22.10 - FUNCTIONS/POWER LOSS
22.10.1 3400 Powerloss function ENUM Disable 0 1 ERWZ FV_
0 Disable
1 Enable
22.10.2 3402 Powerloss accel time s FLOAT 10.0 0.01 100.0 ERW FV_
22.10.3 3404 Powerloss decel time s FLOAT 2.0 0.01 100.0 ERW FV_
22.10.4 3410 Powerloss Vdcref V FLOAT CALCF 0.0 CALCF ERWZS FV_
22.10.5 3420 Powerloss P gain A/V FLOAT CALCF 0.0 100.000 ERWS FV_
22.10.6 3422 Powerloss I time ms FLOAT CALCF 1.0 1000.0 ERWS FV_
22.10.7 3438 Powerloss mode ENUM Ramp down 0 1 ERWZ FV_
0 Ramp down
1 Restart
22.10.8 3440 Powerloss mains src LINK 16 6000 0 16384 ERWZ FV_
L_DIGSEL2
22.11 - FUNCTIONS/COMPARE
22.11.1 3650 Dig compare input 1 perc FLOAT 32 0.0 -100.0 100.0 ERW FVS
22.11.2 3652 Dig compare input 2 perc FLOAT 32 0.0 -100.0 100.0 ERW FVS
