ADV200 • Parameters List 263
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.11.3 3660 Compare input 1 src LINK 32 3650 0 16384 ERW FVS
L_CMP
22.11.4 3662 Compare input 2 src LINK 32 3652 0 16384 ERW FVS
L_CMP
22.11.5 3670 Compare function ENUM None 0 8 ERW FVS
0 None
1 Inp1=Inp2
2 Inp1!=Inp2
3 Inp1<Inp2
4 Inp1>Inp2
5 |Inp1|=|Inp2|
6 |Inp1|!=|Inp2|
7 |Inp1|<|Inp2|
8 |Inp1|>|Inp2|
22.11.6 3672 Compare window perc FLOAT 0.0 0.0 100.0 ERW FVS
22.11.7 3674 Compare delay s FLOAT 0.0 0.0 30.0 ERW FVS
22.11.8 3676 Compare output BIT 16 0 0 1 ER FVS
22.12 - FUNCTIONS/PADS
22.12.1 3700 Pad 1 INT32 32 0 0 0 ERW FVS
22.12.2 3702 Pad 2 INT32 32 0 0 0 ERW FVS
22.12.3 3704 Pad 3 INT32 32 0 0 0 ERW FVS
22.12.4 3706 Pad 4 INT32 32 0 0 0 ERW FVS
22.12.5 3708 Pad 5 INT32 32 0 0 0 ERW FVS
22.12.6 3710 Pad 6 INT32 32 0 0 0 ERW FVS
22.12.7 3712 Pad 7 INT32 32 0 0 0 ERW FVS
22.12.8 3714 Pad 8 INT32 32 0 0 0 ERW FVS
22.12.9 3716 Pad 9 INT32 32 0 0 0 ERW FVS
22.12.10 3718 Pad 10 INT32 32 0 0 0 ERW FVS
22.12.11 3720 Pad 11 INT32 32 0 0 0 ERW FVS
22.12.12 3722 Pad 12 INT32 32 0 0 0 ERW FVS
22.12.13 3724 Pad 13 INT32 32 0 0 0 ERW FVS
22.12.14 3726 Pad 14 INT32 32 0 0 0 ERW FVS
22.12.15 3728 Pad 15 INT32 32 0 0 0 ERW FVS
22.12.16 3730 Pad 16 INT32 32 0 0 0 ERW FVS
22.13 - FUNCTIONS/VDC CONTROL
22.13.1 3450 Vdc control function ENUM Disable 0 1 ERWZ FVS
0 Disable
1 Enable
22.13.2 3470 Vdc control P gain A/V FLOAT CALCF 0.0 100.000 ERWS FVS
22.13.3 3472 Vdc control I time ms FLOAT CALCF 1.0 1000.0 ERWS FVS
22.14 - FUNCTIONS/BRAKE CONTROL
22.14.1 3170 Brake control funct ENUM Disable 0 3 ERWZ FVS
0 Disable
1 Standard
2 Hoist mode 1
3 Hoist mode 2
22.14.2 3172 Brake open delay s FLOAT 0.20 0.0 60.0 ERW FVS
22.14.3 3174 Brake close delay s FLOAT 0.20 0.0 60.0 ERW FVS
22.14.4 3176 Brake open spd thr rpm INT16 0 0 CALCI ERW FVS
22.14.5 3178 Brake close spd thr rpm INT16 0 0 CALCI ERW FVS
