264 ADV200 • Parameters List
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
22.14.6 3194 Brake ramp freeze ENUM Disable 0 1 ERWZ FVS
0 Disable
1 Enable
22.14.7 3182 Brake open thr sel ENUM Output curr 0 1 ERWZ FVS
0 Torque ref%
1 Output curr
22.14.8 3184 Brake open thr perc FLOAT 10 -200.0 200.0 ERWZS FVS
22.14.9 3186 Brake open thr src LINK 16/32 3184 0 16384 ERWZ FVS
L_TCREF
22.14.10 3188 Brake torque time s FLOAT 0.10 0.01 60.0 ERWZ FVS
22.14.11 3190 Brake close wait s FLOAT 2 0.0 60.0 ERW FVS
22.15 - FUNCTIONS/DIMENSION FACT
22.15.1 3900 Dim factor num UINT16 1 1 65535 ERW FVS
22.15.2 3902 Dim factor den UINT16 1 1 65535 ERW FVS
22.15.3 3904 Dim factor text UINT32 7172210 0 0 ERW FVS
22.16 - FUNCTIONS/CONTROL MODE
22.16.1 556 Control mode select ENUM Ramp 0 2 ERWZ F_S
0 Torque
1 Speed
2 Ramp
22.16.2 6200 Ctrl mode src LINK 16 556 0 16384 ERWZ F_S
L_CTRLMODE
22.16.3 6202 Ctrl mode sel 0 src LINK 16 6000 0 16384 ERWZ F_S
L_DIGSEL2
22.16.4 6204 Ctrl mode sel 1 src LINK 16 6000 0 16384 ERWZ F_S
L_DIGSEL2
22.16.5 6206 Ctrl mode sel mon UINT32 0 0 3 ER F_S
22.16.6 6208 Ctrl mode mon ENUM Torque 0 0 ER F_S
0 Torque
1 Speed
2 Ramp
22.17 - FUNCTIONS/TEMP CONTROL
22.17.1 3500 Drv temp src LINK 32 6000 0 16384 ERW FVS
L_TEMPCTRL
22.17.2 3504 Drv temp thr degC INT32 45 1 100 ERW FVS
22.17.3 3508 Drv temp hys degC INT32 2 0 CALCI ERW FVS
22.17.4 3502 Mot temp src LINK 32 6000 0 16384 ERW FVS
L_TEMPCTRL
22.17.5 3506 Mot temp thr degC INT32 45 1 100 ERW FVS
22.17.6 3510 Mot temp hys degC INT32 2 0 CALCI ERW FVS
22.18 - FUNCTIONS/LC CONTROL
22.18.1 6020 Air humidity perc FLOAT 0.0 0.0 0.0 ER FVS
22.18.2 6022 Air temperature degC FLOAT 0.0 0.0 0.0 ER FVS
22.18.3 6032 Dew temperature degC INT16 0 0 0 ER FVS
22.18.4 6034 Dew temp offset off degC INT16 8 3 50 ERW FVS
22.18.5 6048 Dew temp offset on degC INT16 3 2 50 ERW FVS
22.18.6 6036 Liquid temp setpoint degC INT16 0 0 0 ER FVS
22.18.7 6038 Intake liquid temp degC INT16 0 0 0 ER FVS
22.18.8 6040 Liquid temp src LINK 32 6038 0 16384 ERW FVS
