ADV200 • Parameters List 265
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
L_TEMPCTRL
22.18.9 6042 Liquid temp mon degC INT16 0 0 0 ER FVS
22.19 - FUNCTIONS/TIMERS
22.19.1 3550 Timer1 src LINK 32 6000 0 16384 ERW FVS
L_DIGSEL1
22.19.2 3552 Timer1 pos delay s FLOAT 0.10 0.0 30.0 ERW FVS
22.19.3 3554 Timer1 neg delay s FLOAT 0.10 0.0 30.0 ERW FVS
22.19.4 3556 Timer1 mon INT32 0 0 0 ER FVS
22.19.5 3560 Timer2 src LINK 32 6000 0 16384 ERW FVS
L_DIGSEL1
22.19.6 3562 Timer2 pos delay s FLOAT 0.10 0.0 30.0 ERW FVS
22.19.7 3564 Timer2 neg delay s FLOAT 0.10 0.0 30.0 ERW FVS
22.19.8 3566 Timer2 mon INT32 0 0 0 ER FVS
22.20 - FUNCTIONS/TORQUE LIMADAPT
22.20.1 2330 Torque limit high perc FLOAT 100.0 0.0 CALCF ERW F_S
22.20.2 2332 Torque limit low perc FLOAT 70.0 0.0 CALCF ERW F_S
22.20.3 2334 Torque limit ramp ms UINT16 1000 0 60000 ERW F_S
22.20.4 2336 Torque limit sel src LINK 16/32 976 0 16384 ERW F_S
22.20.5 2338 Torque limit adapt perc FLOAT 0.0 0.0 0.0 ER F_S
23 - COMMUNICATION
23.1 - COMMUNICATION/RS485
23.1.1 3800 Drive address UINT16 1 1 255 ERW FVS
23.1.2 3802 Serial baudrate ENUM 38400 0 2 ERW FVS
0 9600
1 19200
2 38400
23.1.3 3810 Serial parameter ENUM N_8_1 0 3 ERW FVS
0 None,8,1
1 None,8,2
2 Even,8,1
3 Odd,8,1
23.1.4 3804 Serial protocol ENUM Modbus 0 1 ERW FVS
0 Modbus
1 Jbus
23.1.5 3806 Serial delay ms UINT16 0 0 1000 ERW FVS
23.1.6 3808 Serial swap data BIT 0 0 1 ERW FVS
23.2 - COMMUNICATION/FIELDBUS CONFIG
23.2.1 4000 Fieldbus type ENUM Off 0 6 RW FVS
0 Off
1 CanOpen
2 DeviceNet
3 Profibus
10 DS402
30 Profidrive
40 Rte
23.2.2 4004 Fieldbus baudrate ENUM 500k 0 12 RW FVS
0 Auto
1 125k
