266 ADV200 • Parameters List
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
2 250k
3 500k
4 1M
5 9600
6 19200
7 93750
8 187,5k
9 1,5M
10 3M
11 6M
12 12M
23.2.3 4006 Fieldbus address INT16 3 0 255 RW FVS
23.2.4 4010 Fieldbus M->S enable ENUM Enable 0 1 ERWZ FVS
0 Disable
1 Enable
23.2.5 4012 Fieldbus alarm mode INT32 0 0 1 ERWZ FVS
23.2.6 4014 Fieldbus state ENUM Stop 0 9 R FVS
0 Stop
1 PreOperational
2 Operational
3 Error
4 WaitPRM
5 WaitCFG
6 DataExchange
7 DPError
8 SafeOp
9 Init
23.2.7 4398 RTE protocol ENUM None 0 0 ER FVS
0 None
1 Ethercat
2 EthernetIP
3 GdNet
4 Profinet
5 ModbusTCP
6 Powerlink
107 Profidrive
23.2.8 5608 IP address UINT32 0 0 4294967295 ER FVS
23.3 - COMMUNICATION/FIELDBUS M->S
23.3.1 4020 Fieldbus M->S1 ipa FBM2SIPA 0 0 20000 RW FVS
23.3.2 4022 Fieldbus M->S1 sys ENUM Not assigned 0 10 RW FVS
0 Not assigned
1 Count 16
2 Count 32
3 Fill 16
4 Fill 32
5 Mdplc 16
6 Mdplc 32
7 Eu
8 Eu float
9 Par 16
10 Par 32
23.3.3 4024 Fieldbus M->S1 mon INT32 16 0 0 0 ERW FVS
23.3.4 4026 Fieldbus M->S1 div FLOAT 1.0 1.0 1000.0 ERW FVS
23.3.5 4030 Fieldbus M->S2 ipa FBM2SIPA 0 0 20000 RW FVS
