ADV200 • Parameters List 283
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
27.3.2 2154 E1 Virtual position cnt UINT32 32 0 0 0 ER FVS
27.3.3 2156 E1 Revolutions INT32 32 0 0 0 ER FVS
27.3.4 2168 E1 Abs pulses UINT32 CALCI 0 0 ER FVS
27.3.5 2164 E1 Abs position cnt UINT32 32 0 0 0 ER FVS
27.3.6 2166 E1 Abs revolutions UINT32 32 0 0 0 ER FVS
27.3.7 5152 E2 Virtual pulses UINT32 CALCI 0 0 ERW FVS
27.3.8 5154 E2 Virtual position cnt UINT32 32 0 0 0 ER FVS
27.3.9 5156 E2 Revolutions INT32 32 0 0 0 ER FVS
27.3.10 5168 E2 Abs pulses UINT32 CALCI 0 0 ER FVS
27.3.11 5164 E2 Abs position cnt UINT32 32 0 0 0 ER FVS
27.3.12 5166 E2 Abs revolutions UINT32 32 0 0 0 ER FVS
27.3.13 5252 E3 Virtual pulses UINT32 CALCI 0 0 ERW FVS
27.3.14 5254 E3 Virtual position cnt UINT32 32 0 0 0 ER FVS
27.3.15 5256 E3 Revolutions INT32 32 0 0 0 ER FVS
27.3.16 2126 Resolver OVR thr V FLOAT 4.820 0.000 4.820 ERWZ FVS
27.3.17 2136 Resolver MIS maxThr V FLOAT 2.280 0.000 4.820 ERWZ FVS
27.3.18 2138 Resolver MIS minThr V FLOAT 3.990 0.000 4.820 ERWZ FVS
27.3.19 2140 Resolver LOT thr deg FLOAT 4 0 9 ERWZ FVS
27.3.20 2142 Resolver LOT hys deg FLOAT 0.5 0 9 ERWZ FVS
27.3.21 2144 Resolver get reg UINT16 0 0 0 ERWZ FVS
27.3.22 2146 Resolver reg mon UINT16 0 0 0 ERZ FVS
27.3.23 2086 Resolver resolution ENUM 16 2 3 ERWZ FVS
2 14 bit
3 16 bit
27.3.24 5312 Encoder fbk mon ENUM E1 Abs 0 0 ER FVS
0 E1 Abs
1 E1 Inc
2 E2 Abs
3 E2 Inc
4 E1 None
5 E2 None
27.4 - SERVICE/FIELDBUS SERV
27.4.1 4016 Fieldbus float order BIT 0 0 1 ERW FVS
27.4.2 4018 Profibus byte order BIT 0 0 1 ERW FVS
27.4.3 5604 InputSize UINT16 0 0 65535 ER FVS
27.4.4 5606 OutputSize UINT16 0 0 65535 ER FVS
27.4.5 5614 PN diagnostic UINT32 0 0 4294967295 ERW FVS
27.4.6 5616 MDPlc direct map INT32 0 0 1 ERWZ FVS
27.5 - SERVICE/EXT IO SERV
27.5.1 5488 External IO period UINT16 8 8 64 ERW FVS
27.5.2 5490 External IO address INT16 1 1 255 ERW FVS
27.5.3 5492 External IO baudrate ENUM 500k 0 12 ERW FVS
0 Auto
1 125k
2 250k
3 500k
4 1M
5 9600
6 19200
7 93750
8 187,5k
