284 ADV200 • Parameters List
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
9 1,5M
10 3M
11 6M
12 12M
27.5.4 5494 External IO lifetime UINT16 3 1 100 ERW FVS
27.5.5 5496 External IO err cnt UINT16 0 0 65535 ERW FVS
27.5.6 4980 ExtIO holdoff ms UINT16 1 1 10000 ERW FVS
27.5.7 4982 External IO pdo time UINT16 4 1 10000 ERW FVS
27.5.8 4984 External IO HB time ms UINT16 100 8 10000 ERW FVS
27.6 - SERVICE/FAST LINK SERV
27.6.1 4946 FL fault holdoff us UINT16 250 125 10000 ERW FVS
27.6.2 5790 FLRxTimeoutHoldOff UINT16 4 0 4000 ERW FVS
27.6.3 5792 FLRxTimeoutCnt UINT16 0 0 0 ER FVS
27.6.4 5794 FLSyncSlaveEHoldOff UINT16 4 0 4000 ERW FVS
27.6.5 5796 FLSyncSlaveErrCnt UINT16 0 0 0 ER FVS
27.7 - SERVICE/SERIAL NUMBERS
27.7.1 520 Product S/N UINT32 0 0 0 R FVS
27.7.2 522 Regulation S/N UINT32 0 0 0 R FVS
27.7.3 524 Power S/N UINT32 0 0 0 R FVS
27.7.4 536 Slot1 card S/N UINT32 0 0 0 R FVS
27.7.5 538 Slot2 card S/N UINT32 0 0 0 R FVS
27.7.6 540 Slot3 card S/N UINT32 0 0 0 R FVS
27.8 - SERVICE/SENSORLESS VF
27.8.1 3356 Magn curr speed zero perc UINT32 150 50 200 ERW __S
27.8.2 3384 Vf catch min time ms UINT16 600 1 20000 ERW _V_
27.8.3 2456 AC brake max time ms FLOAT 20000 1 60000.0 ERWS _V_
27.8.4 2458 AC brake max curr perc UINT16 150 101 200 ERWS _V_
27.8.5 2496 Steady curr filter FLOAT 10.0 0.0 1000.0 ERWZ _V_
27.9 - SERVICE/CURRENTS
27.9.1 80 Phase current U A FLOAT 0.0 0.0 0.0 ER FVS
27.9.2 82 Phase current V A FLOAT 0.0 0.0 0.0 ER FVS
27.9.3 84 Phase current W A FLOAT 0.0 0.0 0.0 ER FVS
27.9.4 90 Phase current RMS U A FLOAT 0.0 0.0 0.0 ER FVS
27.9.5 92 Phase current RMS V A FLOAT 0.0 0.0 0.0 ER FVS
27.9.6 94 Phase current RMS W A FLOAT 0.0 0.0 0.0 ER FVS
27.9.7 78 Phase current filter ms UINT16 0 0 20 ERW FVS
27.10 - SERVICE/MOTOR PHLOSS
27.10.1 4676 Mot PhLoss magn time ms UINT16 5000 1000 20000 ERW FVS
27.10.2 4688 Mot PhLoss wait ms UINT16 1000 0 10000 ERW FVS
27.10.3 4694 Mot PhLoss SRL delay ms UINT16 200 0 1000 ERW FVS
27.11 - SERVICE/LC SERV
27.11.1 200 Thermal_resistance1 degC/W FLOAT 0.02 0 1 ERWS FVS
27.11.2 202 Thermal_resistance2 degC/W FLOAT 0 0 1 ERWS FVS
27.11.3 206 Powerloss factor1 FLOAT 0.005 0 1 ERWS FVS
27.11.4 210 Liquid temp filter ms UINT16 1000 0 10000 ERW FVS
