gefran ADV200 User Manual

ADV200 • Parameters List 285
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
27.11.5 212 Powerloss factor2 FLOAT 0 0 1 ERWS FVS
27.11.6 4594 HumTSensErr activity ENUM Disable 0 4 ERW FVS
0 Ignore
1 Warning
2 Disable
3 Stop
4 Fast stop
27.11.7 4580 HumTSensErr holdoff s UINT16 3 1 50 ERW FVS
27.11.8 6052 LC sens err enable UINT16 2 0 0 ERWS FVS
27.12 - SERVICE/MAGNETIZATION
27.12.1 2500 DSP enabler code UINT32 38991 0 4294967295 ERW FVS
27.12.2 2502 SoftScope N page UINT16 0 0 65535 ERW FVS
27.13 - SERVICE/OBSOLETE PARAMS
27.13.1 2400 Voltage flux boost perc FLOAT 0.0 0.0 15.0 ERWS _V_
27.13.2 2402 Voltage boost gain V/A FLOAT 0.0 0.0 0.0 ERWS _V_
27.13.3 2470 Damping gain perc UINT16 0 0 100 ERW _V_
27.13.4 2472 Damping threshold 1 Hz INT16 20 5 100 ERW _V_
27.13.5 2474 Damping threshold 2 Hz INT16 30 5 100 ERW _V_
27.13.6 2508 Motor temp K FLOAT 0 0.0 0 ERW FVS
27.14 - SERVICE/FILTERS
27.14.1 30 Display spd filter ms UINT16 200 10 1000 ERW FVS
27.14.2 32 Display trq filter ms UINT16 200 10 1000 ERW FVS
27.14.3 34 Display cosphi filt ms UINT16 600 0 1000 ERW FVS
27.15 - SERVICE/TEST VAR
27.15.1 5060 Var 1 addr UINT32 3759169536 0 0 ERW FVS
27.15.2 5062 Var 2 addr UINT32 3759169536 0 0 ERW FVS
27.15.3 5070 Var 1 type ENUM Not assigned 0 2 ERW FVS
0 Not assigned
1 Count 16
2 Count 32
27.15.4 5072 Var 2 type ENUM Not assigned 0 2 ERW FVS
0 Not assigned
1 Count 16
2 Count 32
27.15.5 5080 Var 1 mon INT32 0 0 0 ER FVS
27.15.6 5082 Var 2 mon INT32 0 0 0 ER FVS
27.16 - SERVICE/OBSERVER
27.16.1 2570 Flux obsv gain FLOAT 1.0 0.0 5.0 ERWS F_S
27.16.2 2572 Flux obsv enable BIT 0 0 1 ERWS F_S
27.16.3 2574 Flux obsv filter tau ms FLOAT 4.0 0.01 10.0 ERWS F_S
27.16.4 2576 Flux obsv speed thrd perc FLOAT 15.0 0.0 400.0 ERWS F_S
27.17 - SERVICE/SD CARD
27.17.1 598 Load from SD card BIT 0 0 1 ERWZ FVS
28 - RECIPE CONFIG
28.1 6300 Recipe config 1 UINT16 0 0 0 RW FVS
