72 ADV200 • Functions description and parameters list
0V..+10V Less than 4 mA saturation at
Bottom
Top
4..20 mA Bottom Top
The Analog inputs voltage or current inputs must be congured on the external module using a dedicated
switch or tool. For analog input 0 and analog input 1 the An input type parameter must be set according to the
type of external device.
Menu PAR Description UM Type FB BIT Def Min Max Acc Mod
14.65 1586 Sensor inp X type ENUM None 0 3 ERW FVS
0 None
1 Klixon
2 KTY84
3 PTC
Setting of sensor type connected to dedicated input of temperature expansion cards EXP-IO-SENS-100-ADV
or EXP-IO-SENS-1000-ADV.
When these cards are used, alarm [62] An inpLoss signals the disconnection or short circuit of the KTY84 or
PTC sensor.
