ADV200 • Functions description and parameters list 71
facturer.
E.g.:
12-bit module
Signal connected
Module configuration
Variant 1 Variant 2 Variant 3 Variant 4
-10V..+10V -2048..+2047 -32768..+32767 -16384..+16383
0V..+10V 0..+4095 0..+2047 0..+32767 0..+65535
4..20mA 0..+32767 +6553..+32767 +3276..+16383
16-bit module
Signal connected
Module configuration
Variant 1 Variant 2 Variant 3
-10V..+10V -32768..+32767
0V..+10V 0..+65535 0..+32767
4..20mA
There is no single Unit suitable for all models of analog input module. Check the scaling provided by the model
being used and use the system variables accordingly.
Analog input 0 and analog input 1 can also be managed by the drive parameters. To ensure correction opera-
tion, the scaling provided by the external module must be compatible with the scaling requested by the drive.
The drive needs I/O modules that supply datum scaled as follows
Analog inp X type Range
-10V..+10V -32768..+32767
0V..+10V 0..+65535
4..20mA +13107..+65535
When the An inp X gain tune (PAR 1508, PAR1558) command is sent with analog input set to the maximum
value, the gain needed to adjust the full scale value is calculated.
For modules with scaling other than that requested by the drive, the An inp X gain tune command attempts to
adjust the scaling. For that reason the maximum value is increased for An inp X gain tune parameters.
The tables below show the output of the analog input block according to the signal connected and the congu-
ration of the Analog inp X type parameter (PAR 1502, PAR1552).
Signal connected: -10V..+10V
An input type -10V 0V +10V
-10V..+10V Bottom Obtained from straight line Top
0V..+10V Less than 0V saturation at
Bottom
Bottom Top
4.0.20 mA Less than 2V saturation at
Bottom
Bottom Top
Signal connected: 0V..+10V
An input type 0V +10V
-10V..+10V Obtained from straight line Top
0V..+10V Bottom Top
4..20 mA Less than 2V saturation at
Bottom
Top
Signal connected: 4..20 mA
An input type 4mA 20mA
-10V..+10V Top
